BCM (BODY CONTROL MODULE) EXL-127 < ECU DIAGNOSIS INFORMATION > [XENON TYPE] C D E F G H I J K M A B EXL N O P 144 (P) Ground Combination switch Output Combination All switches OFF 0 V Front washer switch ON 10.7 V Rear wiper switch ON Rear washer switch ON Any of the conditions below 145 (V) Ground Combination switch Output Combination All switches OFF 0 V Front wiper switch INT/ 10.7 V Front wiper switch LO Lighting switch AUTO 146 (Y) Ground Combination switch Output Combination All switches OFF 0 V Front fog lamp switch ON 10.7 V Lighting switch 2ND Lighting switch PASS Turn signal switch LH 149 Ground Tire pressure warn- Input Ignition switch ON 11.8 V 150 (SB) Ground Driver door switch Input Driver door OFF (When driver door 11.8 V ON (When driver door 0 V Terminal No. (Wire color) Description Condition Value (Approx.) Signal name Input/ Output + – JPMIA0033GB JPMIA0034GB JPMIA0035GB JPMIA0011GB JPMIA0011GB |
