BCS BCM (BODY CONTROL MODULE) BCS-67 < ECU DIAGNOSIS INFORMATION > C D E F G H I J K L B A O P N 124 (R) Ground Passenger door Input Passenger door OFF (When passenger 11.8 V ON (When passenger door 0 V 130* 2 (BR) Ground Rear window defog- Input Ignition switch Rear window defogger 1.1 V Rear window defogger 0 V 132 (G) Ground Power window switch Input/ Output Ignition switch ON 10.2 V Ignition switch OFF or ACC Battery voltage 133 Ground Push-button ignition Output Push-button igni- ON (When tail lamps OFF) 9.5 V ON (When tail lamps ON) NOTE: The pulse width of this wave is varied by the illumination bright- ening/dimming level. OFF 0 V 134 (R) Ground LOCK indicator lamp Output LOCK indicator OFF (ACC and ON indica- Battery voltage ON 0 V 137 (P) Ground Receiver and sensor Input Ignition switch ON 0 V 138 (V) Ground Receiver and sensor Output Ignition switch OFF 0 V ACC or ON 5.0 V Terminal No. (Wire color) Description Condition Value (Approx.) Signal name Input/ Output + – JPMIA0011GB JPMIA0012GB JPMIA0013GB JPMIA0159GB |
