TRANSAXLE ASSEMBLY TM-175 < UNIT REMOVAL AND INSTALLATION > [CVT: RE0F09B] C E F G H I J K L M A B TM N O P When installing transaxle assembly to the engine assembly, attach • When using the drive plate location guide (commercial service tool: 31197CA000) (A), set it to the stud bolts which is used to install it • When not using drive plate location guide, rotate torque converter so that the stud bolt (B) for mounting the drive plate location guide • Rotate crankshaft so that the hole (A) for inserting drive plate loca- tion guide of drive plate aligns with the service hole (B). CAUTION: Be careful not to strike the drive plate when installing the • Align the position of tightening nuts ( ) for drive plate with those of the torque converter, and temporarily tighten the nuts. Then, CAUTION: • When turning crankshaft, turn it clockwise as viewed from the front of the engine. • When tightening the nuts for the torque converter after fixing the crankshaft pulley bolts, confirm the tightening torque of . JPDIA0600ZZ Insertion direction Transaxle assembly to engine assembly Engine assembly to tran- saxle assembly Bolt position A B C D Number of bolts 1 2 2 4 Bolt length mm (in) 55 (2.17) 39 (1.54) 108 (4.25) 45 (1.77) Tightening torque 74.5 (7.6, 55) 50 (5.1, 37) JPDIA0607ZZ JPDIA0603ZZ : 51 N·m (5.2 kg-m, 38 ft-lb) SCIA1861E |
