PCS-94 < ECU DIAGNOSIS INFORMATION > [POWER DISTRIBUTION SYSTEM] BCM (BODY CONTROL MODULE) 111* 1 (LG) Ground Steering lock unit Input/ Output Steering lock LOCK status Battery voltage LOCK or UNLOCK For 15 seconds after UN- Battery voltage 15 seconds or later after 0 V 112 (R) Ground Rain sensor serial Input/ Output Ignition switch ON 8.7 V 113 (O) Ground Optical sensor Input Ignition switch When bright outside of the Close to 5 V When dark outside of the Close to 0 V 116 (GR) Ground Stop lamp switch 1 Input — Battery voltage 118 (L) Ground Stop lamp switch 2 Input Stop lamp switch OFF (Brake pedal is not 0 V ON (Brake pedal is de- Battery voltage 119 Ground Front door lock as- Input Driver door LOCK status (unlock sen- 1.1 V UNLOCK status (unlock 0 V 121 (Y) Ground Key slot switch Input When Intelligent Key is inserted into key slot Battery voltage When Intelligent Key is not inserted into key slot 0 V 123 (G) Ground IGN feedback Input Ignition switch OFF or ACC 0 V ON Battery voltage Terminal No. (Wire color) Description Condition Value (Approx.) Signal name Input/ Output + – JMKIA0066GB JPMIA0156GB JPMIA0012GB |
