MIR-28

< ECU DIAGNOSIS INFORMATION >

[WITH ADP]

DRIVER SEAT CONTROL UNIT

6

(R/L)

Ground

Reclining motor forward
output signal

Output

Seat reclining

Operate

 (forward)

Battery voltage

Release

0

7

(L)

Ground

Lifting motor (rear) down
output signal

Output

Seat lifting (rear)

Operate

(down)

Battery voltage

Stop

0

8

(L/W)

Ground

Lifting motor (rear) up out-
put signal

Output

Seat lifting (rear)

Operate

(up)

Battery voltage

Stop

0

9

(L/R)

Ground

Lifting motor (front) down
output signal

Output

Seat lifting (front)

Operate

(down)

Battery voltage

Stop

0

10

(L/B)

Ground

Lifting motor (front) up out-
put signal

Output

Seat lifting (front)

Operate

(up)

Battery voltage

Stop

 0

11

(G/B)

Ground

Sliding switch backward
signal

Input

Sliding switch

Operate

(backward)

0

Release

Battery voltage

12

(G/W)

Ground

Sliding switch forward sig-
nal

Input

Sliding switch

Operate

 (forward)

0

Release

Battery voltage

13

(R/G)

Ground

Reclining switch backward
signal

Input

Reclining switch

Operate

(backward)

0

Release

Battery voltage

14

(R/W)

Ground

Reclining switch forward
signal

Input

Reclining switch

Operate

 (forward)

0

Release

Battery voltage

15

(Y/B)

Ground

Lifting switch (rear) down
signal

Input

Lifting switch

(rear)

Operate

(down)

0

Release

Battery voltage

16

(Y/R)

Ground

Lifting switch (rear) up sig-
nal

Input

Seat lifting switch

(rear)

Operate

 (up)

0

Release

Battery voltage

17

(LG/B)

Ground

Lifting switch (front) down
signal

Input

Lifting switch

(front)

Operate

(down)

0

Release

Battery voltage

18

(LG/R)

Ground

Lifting switch (front) up sig-
nal

Input

Seat lifting switch

(front)

Operate

 (up)

0

Release

Battery voltage

19

(G/Y)

Ground

Sliding sensor signal

Input

Seat sliding

Operate

Stop

0 or 5

Terminal No.

(wire color)

Description

Condition

Voltage (V)

(Approx)

+

-

Signal name

Input/

Output

JMJIA0119ZZ

DRIVER SEAT CONTROL UNIT

MIR-29

< ECU DIAGNOSIS INFORMATION >

[WITH ADP]

C

D

E

F

G

H

I

J

K

M

A

B

MIR

N

O

P

20

(R/Y)

Ground

Reclining sensor signal

Input

Seat reclining

Operate

Stop

0 or 5

21

(L/Y)

Ground

Lifting sensor (rear) signal

Input

Seat lifting (rear)

Operate

Stop

0 or 5

22

(BR/Y)

Ground

Lifting sensor (front) signal

Input

Seat lifting (front)

Operate

Stop

0 or 5

23

(P)

—

CAN-H

—

—

—

24

(P/L)

—

CAN-L

—

—

—

25

(G/O)

Ground

Memory indictor 1 signal

Output

Memory indictor 1

Illuminate

1

Other than above

Battery voltage

26

(L/O)

Ground

Memory indictor 2 signal

Output

Memory indictor 2

Illuminate

1

Other than above

Battery voltage

27

(V)

Ground

Memory switch 1 signal

Input

Memory switch 1

Press

0

Other than above

5

28

(V/W)

Ground

Memory switch 2 signal

Input

Memory switch 2

Press

0

Other than above

5

29

(O/L)

Ground

Set switch signal

Input

Set switch

Press

0

Other than above

5

30

(BR)

Ground

Tilt sensor signal

Input

Tilt

Operate

Other than above

0 or 5

Terminal No.

(wire color)

Description

Condition

Voltage (V)

(Approx)

+

-

Signal name

Input/

Output

JMJIA0119ZZ

JMJIA0119ZZ

JMJIA0119ZZ

JMJIA0119ZZ

MIR-30

< ECU DIAGNOSIS INFORMATION >

[WITH ADP]

DRIVER SEAT CONTROL UNIT

31

(BR/W)

Ground

Telescopic sensor signal

Input

Telescopic

Operate

Other than above

0 or 5

32

(W/L)

Ground

UART communication
(TX/RX)

Input

Ignition switch ON

33

(W)

Ground

Sensor power supply

Output

—

Battery voltage

Terminal No.

(wire color)

Description

Condition

Voltage (V)

(Approx)

+

-

Signal name

Input/

Output

JMJIA1391ZZ

DRIVER SEAT CONTROL UNIT

MIR-31

< ECU DIAGNOSIS INFORMATION >

[WITH ADP]

C

D

E

F

G

H

I

J

K

M

A

B

MIR

N

O

P

Wiring Diagram - AUTOMATIC DRIVE POSITIONER CONTROL SYSTEM -

INFOID:0000000005716144

JCJWM0709GB
