OIL COOLER LU-13 < REMOVAL AND INSTALLATION > C D E F G H I J K L M A LU N P O 2. Drain engine coolant from radiator and cylinder block. Refer to NOTE: 3. Remove oil filter. Refer to LU-11, "Removal and Installation" CAUTION: Never spill engine oil on drive belt. 4. Disconnect water hoses from oil cooler. ing out. • Remaining engine coolant in piping will come out. Use a tray to collect it. CAUTION: • Perform this step when the engine is cold. 5. Remove connector bolt, and remove oil cooler. CAUTION: Never spill engine oil to rubber parts such as drive belt. 6. Remove water pipes if necessary. INSTALLATION Note the following, and install in the reverse order of removal. (upper) side, and tighten connector bolt (1). Inspection INFOID:0000000009718812 INSPECTION AFTER REMOVAL Oil Cooler Check oil cooler for cracks. Check oil cooler for clogging by blowing through engine coolant inlet. If necessary, Relief Valve Inspect relief valve for movement, cracks and breaks by pushing the ball. If replacement is necessary, remove INSPECTION AFTER INSTALLATION 1. Check the engine oil level and the engine coolant level and add engine oil and engine coolant. Refer to 2. Start the engine, and check there is no leakage of engine oil or engine coolant. 3. Stop the engine and wait for 10 minutes. 4. Check the engine oil level and the engine coolant level again. Refer to JPBIA1680ZZ |
