EC-54 < SYSTEM DESCRIPTION > [VQ35DE] ELECTRIC IGNITION SYSTEM 1. Mas air flow sensor (with intake air 2. Electric throttle control actuator : Vehicle front 1. Ignition coil (with power transistor) 2. Fuel injector (bank 1) 3. Fuel injector (bank 2) 4. Ignition coil (with power transistor) 5. Knock sensor (bank 2) 6. Knock sensor (bank 1) : Vehicle front 1. Crankshaft position sensor (POS) 2. Camshaft position sensor (PHASE) 3. Camshaft position sensor (PHASE) : Vehicle front JMBIA1109ZZ JMBIA1110ZZ JMBIA1114ZZ |
