FSU-24
< SERVICE DATA AND SPECIFICATIONS (SDS)
SERVICE DATA AND SPECIFICATIONS (SDS)
SERVICE DATA AND SPECIFICATIONS (SDS)
SERVICE DATA AND SPECIFICATIONS (SDS)
Wheel Alignment
INFOID:0000000010822767
Measure value under unladen*
2
conditions.
*1: A difference when assuming the left side a standard.
*2: Fuel, engine coolant and lubricant are full. Spare tire, jack, hand tools and mats are in designated positions.
Ball Joint
INFOID:0000000010822768
Wheelarch Height
INFOID:0000000010822769
2ROW
Item
Standard
Camber
Degree minute (Decimal degree)
Minimum
–1
°
15
′
(–1.25
°
)
Nominal
–0
°
30
′
(–0.50
°
)
Maximum
0
°
15
′
(0.25
°
)
Left and right difference*
1
–0
°
35
′
(–0.58
°
) - 0
°
35
′
(0.58
°
)
Caster
Degree minute (Decimal degree)
Minimum
4
°
50
′
(4.84
°
)
Nominal
5
°
35
′
(5.58
°
)
Maximum
6
°
20
′
(6.33
°
)
Left and right difference*
1
–0
°
35
′
(–0.58
°
) - 0
°
35
′
(0.58
°
)
Kingpin inclination
Degree minute (Decimal degree)
Minimum
10
°
55
′
(10.92
°
)
Nominal
11
°
40
′
(11.67
°
)
Maximum
12
°
25
′
(12.41
°
)
Toe-in
Total toe-in
Distance
Minimum
Out 0.2 mm (Out 0.008 in)
Nominal
In 1.8 mm (In 0.071 in)
Maximum
In 3.8 mm (In 0.150 in)
Total toe-angle
Degree minute
(Decimal degree)
Minimum
Out 0
°
04
′
(Out 0.06
°
)
Nominal
In 0
°
08
′
(In 0.13
°
)
Maximum
In 0
°
20
′
(In 0.33
°
)
Item
Standard
Swing torque
0.5 – 3.4 N·m (0.06 – 0.34 kg-m, 5 – 30 in-lb)
Measurement on spring balance
13.5 – 91.9 N (1.4 – 9.4 kg, 3 – 21 lb)
Axial end play
0 mm (0 in)
Item
Standard
Engine
MR20DD/QR25DE
R9M
Drive
2WD
4WD
2WD
4WD
Tire Size
17 inch
18 inch
17 inch
18 inch
17 inch
19 inch
17 inch
18 inch
19 inch
Front (Hf)
800 mm
(31.50 in)
803 mm
(31.61 in)
799 mm
(31.46 in)
801 mm
(31.54 in)
797 mm
(31.38 in)
802 mm
(31.57 in)
796 mm
(31.34 in)
799 mm
(31.46 in)
802 mm
(31.57 in)
