Nissan Qashqai J11. Manual - part 2231
DAS-338
< ECU DIAGNOSIS INFORMATION >
[PARK ASSIST]
AROUND VIEW MONITOR CONTROL UNIT
Fail-safe (Around View Monitor Control Unit)
INFOID:0000000010504557
If a malfunction occurs in the Around View Monitor control unit, display control unit performs fail-safe activation
according to the detected malfunction.
38
(L)
Ground
Front camera power supply
Output
ON
CAMERA selected
or
Shift selector in R (reverse)
position.
6.0 V
40
(LG)
39
(Shield)
Front camera image signal
Input
ON
CAMERA selected
or
Shift selector in R (reverse)
position.
Terminal
(Wire color)
Description
Condition
Reference value
(Approx.)
+
–
Signal name
Input/
Output
Ignition
switch
Operation
JSNIA0834GB
Detection item
fail-safe
DTC
CONTROL UNIT (CAN)
The Around View Monitor system does not operate
U1010
POWER SUPPLY CIRCUIT
Stops Around View Monitor with park assist
C1A01
VHCL SPEED SE CIRC
• Stops BSW (Blind Spot Warning)
• Stops the MOD (Moving Object Detection) function
• Stops Around View Monitor with park assist
C1A03
ABS/TCS/VDC CIRC
C1A04
VDC P-RUN DIAGNOSIS
• Stops BSW (Blind Spot Warning)
• Stops the MOD (Moving Object Detection) function
• Stops Around View Monitor with park assist
U0122
VDC CHECKSUM
• Stops BSW (Blind Spot Warning)
• Stops the MOD (Moving Object Detection) function
• Stops Around View Monitor with park assist
U0416
ECM CIRCUIT
Stops Around View Monitor with park assist
C1A14
STRG SEN CIR
• Stops BSW (Blind Spot Warning)
• Stops the MOD (Moving Object Detection) function
• Stops Around View Monitor with park assist
C1A39
ST ANGLE SEN CALIB
• Predicted course lines are not displayed
• Stops the MOD (Moving Object Detection) function
• Stops BSW (Blind Spot Warning)
• Stops Around View Monitor with park assist
U1232
ST ANGLE SENSOR CALIBRATION
U0428
CAM COMM CIR-
CUIT
Steering angle
sensor
• Predicted course lines are not displayed
• Stops the MOD (Moving Object Detection) function
• Stops BSW (Blind Spot Warning)
• Stops Around View Monitor with park assist
U1000
ABS actuator
and electric unit
(control unit)
• Stops the MOD (Moving Object Detection) function
• Stops BSW (Blind Spot Warning)
• Stops Around View Monitor with park assist
TCM
BCM
ECM
EPS control unit
Stops Around View Monitor with park assist
NAVI control unit
Camera screen not displayed
