AUTO RETRACTABLE DOOR MIRROR DOES NOT OPERATE MIR-63 < SYMPTOM DIAGNOSIS > C D E F G H I J K M A B MIR N O P AUTO RETRACTABLE DOOR MIRROR DOES NOT OPERATE Diagnosis Procedure INFOID:0000000011378324 1. CHECK INTELLIGENT KEY AND DOOR REQUEST SWITCH OPERATION Check operation of Intelligent Key and door request switch. YES >> GO TO 2. NO >> Repair or replace the malfunctioning parts. 2. CHECK DOOR MIRROR (OPEN/CLOSE MOTOR) CIRCUIT Check door mirror (open/close motor) circuit. MIR-54, "Component Function Check" . Is the inspection result normal? YES >> GO TO 3. NO >> Repair or replace the malfunctioning parts. 3. CHECK AUTO RETRACTABLE DOOR MIRROR CIRCUIT Check auto retractable door mirror circuit. MIR-59, "Component Function Check" . Is the inspection result normal? YES >> GO TO 4. NO >> Repair or replace the malfunctioning parts. 4. CONFIRM THE OPERATION Confirm the operation again. YES >> Check intermittent incident. Refer to GI-44, "Intermittent Incident" . NO >> GO TO 1. |
