PREPARATION

EM-131

< PREPARATION >

[MR20DD]

C

D

E

F

G

H

I

J

K

L

M

A

EM

N

P

O

Valve seat cutter set

Finishing valve seat dimensions

Piston ring expander

Removing and installing piston ring

Valve guide drift

Removing and installing valve guide

Valve guide reamer

 Reaming valve guide inner hole

 Reaming hole for oversize valve guide

Oxygen sensor thread cleaner

Reconditioning the exhaust system threads
before installing a new heated oxygen sensor
(Use with anti-seize lubricant shown below.)
a: 18 mm (0.71 in) dia. for zirconia heated
oxygen sensor
b: 12 mm (0.47 in) dia. for titania heated ox-
ygen sensor

Anti-seize lubricant (Permatex 133AR
or equivalent meeting MIL specifica-
tion MIL-A-907)

Lubricating oxygen sensor thread cleaning
tool when reconditioning exhaust system
threads

Tool name

Description

S-NT048

S-NT030

PBIC4012E

PBIC4013E

AEM488

AEM489

EM-132

< PREPARATION >

[MR20DD]

PREPARATION

Lubricant or/and Sealant

INFOID:0000000010715451

Manual lift table caddy

Removing and installing engine

Tube presser

Pressing the tube of liquid gasket

Tool name

Description

ZZA1210D

S-NT052

Name

Description

Note

Three bond 1215

Cylinder block

Water drain plug

Three bond 1217H

• Oil pan (lower)
• Rocker cover
• Timing chain
• Oil pan (upper)
• Camshaft
• Cylinder block

—

Three bond 1386B

Cylinder block

Plug

CAMSHAFT VALVE CLEARANCE

EM-133

< BASIC INSPECTION >

[MR20DD]

C

D

E

F

G

H

I

J

K

L

M

A

EM

N

P

O

BASIC INSPECTION

CAMSHAFT VALVE CLEARANCE

Inspection and Adjustment

INFOID:0000000010715452

INSPECTION

Perform inspection as follows after removal, installation or replacement of camshaft or valve-related parts, or if
there is unusual engine conditions regarding valve clearance.
1.

Remove rocker cover. Refer to

EM-170, "Exploded View"

.

2.

Measure the valve clearance with the following procedure:

a.

Set No. 1 cylinder at TDC of its compression stroke.
• Rotate crankshaft pulley

 clockwise and align TDC mark (no

paint)

 to timing indicator

 on front cover.

• At the same time, check that both intake and exhaust cam

noses of No. 1 cylinder face inside (

) as shown in the figure.

• If they do not face inside, rotate crankshaft pulley once more

(360 degrees) and align as shown in the figure.

b.

Using a feeler gauge, measure the clearance between valve
lifter and camshaft.

: White paint mark (Not use for service)

PBIC3960E

: Camshaft (INT)

: Camshaft (EXH)

: Engine front

JPBIA4347ZZ

Valve clearance

: Refer to

EM-249, "Camshaft"

.

PBIC3192J

EM-134

< BASIC INSPECTION >

[MR20DD]

CAMSHAFT VALVE CLEARANCE

• By referring to the figure, measure the valve clearances at

locations marked “

×

” as shown in the table below [locations

indicated with black arrow (

) in the figure] with a feeler

gauge.

c.

Set No. 4 cylinder at TDC of its compression stroke.
• Rotate crankshaft pulley

 one revolution (360 degrees) and

align TDC mark (no paint)

 to timing indicator

 on front

cover.

• By referring to the figure, measure the valve clearance at loca-

tions marked “

×

” as shown in the table below [locations indi-

cated with black arrow (

) in the figure] with a feeler gauge.

3.

If out of standard, perform adjustment. Refer to “ADJUSTMENT”.

ADJUSTMENT

• Perform adjustment depending on selected head thickness of valve lifter.

1.

Remove camshaft. Refer to

EM-196, "Exploded View"

.

2.

Remove valve lifters at the locations that are out of the standard.

: Exhaust side

: No. 1 cylinder

: No. 2 cylinder

: No. 3 cylinder

: No. 4 cylinder

: Intake side

: Engine front

JPBIA5120ZZ

Measuring position

No. 1 CYL.

No. 2 CYL.

No. 3 CYL.

No. 4 CYL.

No. 1 cylinder at compression TDC

EXH

×

×

INT

×

×

: White paint mark (Not use for service)

PBIC3960E

: Exhaust side

: No. 1 cylinder

: No. 2 cylinder

: No. 3 cylinder

: No. 4 cylinder

: Intake side

: Engine front

JPBIA5121ZZ

Measuring position

No. 1 CYL.

No. 2 CYL.

No. 3 CYL.

No. 4 CYL.

No. 4 cylinder at compression TDC

EXH

×

×

INT

×

×
