NOTE:

*: Check digit means a single number, or letter X,

used to verify the accuracy of transcription of vehicle
identification number.

VEHICLE IDENTIFICATION NUMBER LIST

VEHICLES FOR USA

(FOR FEDERAL EMISSION REGULATION)

VIN (except sequence number) Brand

Engine
displacement

Model code

JA4MS31X_7U

MITSUBISHI
OUTLANDER

3.0L

CW6WXLSYL2M

JA4MS41X_7U

CW6WXLHYL2M
CW6WXLXYL2M

JA4MT31X_7U

CW6WXLSYZL2M

JA4MT41X_7U

CW6WXLHYZL2M
CW6WXLXYZL2M

(FOR CALIFORNIA EMISSION REGULATION)

VIN (except sequence number) Brand

Engine
displacement

Model code

JA4MS31X_7U

MITSUBISHI
OUTLANDER

3.0L

CW6WXLSYL7M

JA4MS41X_7U

CW6WXLHYL7M
CW6WXLXYL7M

JA4MT31X_7U

CW6WXLSYZL7M

JA4MT41X_7U

CW6WXLHYZL7M
CW6WXLXYZL7M

VEHICLES FOR PUERTO RICO

VIN (except sequence number) Brand

Engine
displacement

Model code

JA4MS31X_7U

MITSUBISHI
OUTLANDER

3.0L

CW6WXLSYL2M
CW6WXLMYL2M

JA4MS41X_7U

CW6WXLXYL2M

JA4MT31X_7U

CW6WXLSYZL2M

VEHICLES FOR CANADA

VIN (except sequence number) Brand

Engine
displacement

Model code

JA4MS31X_7U

MITSUBISHI
OUTLANDER

3.0L

CW6WXLSYL3M

JA4MS41X_7U

CW6WXLXYL3M

JA4MT31X_7U

CW6WXLSYZL3M

JA4MT41X_7U

CW6WXLXYZL3M

GENERAL

00-11

VEHICLE IDENTIFICATION

GENERAL DATA AND SPECIFICATIONS

M20000000300USA0000010000

<Except vehicles for CANADA>

ZC5019470000

5
2

9

7

4
1

8

3

6

Item

CW6W
XLSYL2M/7M

XLHYL2M/7M

XLSYZL2M/7M XLHYZL2M/7M

Vehicle
dimension mm
(in)

Overall length

1 4,640 (182.7)

4,640 (182.7)

4,640 (182.7)

4,640 (182.7)

Overall width

2 1,800 (70.9)

1,800 (70.9)

1,800 (70.9)

1,800 (70.9)

Overall

 height

(unladen)

3 1,680 (66.1)

<Vehicles
without

 roof

rail>
1,720 (67.7)
<Vehicles  with
roof rail>

1,720 (67.7)
<Vehicles  with
roof rail>

1,680 (66.1)
<Vehicles
without

 roof

rail>
1,720 (67.7)
<Vehicles  with
roof rail>

1,720 (67.7)
<Vehicles  with
roof rail>

Wheelbase

4 2,670 (105.1)

2,670 (105.1)

2,670 (105.1)

2,670 (105.1)

Tread-front

5 1,540 (60.6)

1,540 (60.6)

1,540 (60.6)

1,540 (60.6)

Tread-rear

6 1,540 (60.6)

1,540 (60.6)

1,540 (60.6)

1,540 (60.6)

Overhang-front

7 965 (38.0)

965 (38.0)

965 (38.0)

965 (38.0)

Overhang-rear

8 1,005 (39.6)

1,005 (39.6)

1,005 (39.6)

1,005 (39.6)

Ground clearance 9 215 (8.5)

215 (8.5)

215 (8.5)

215 (8.5)

Vehicle weight
kg (lb)

Curb weight

1,615 (3,560)

1,635 (3,604)

1,680 (3,703)

1,700 (3,747)

Gross  vehicle  weight
rating

2,300 (5,071)

2,350 (5,181)

2,350 (5,181)

Gross  axle  weight
rating-front

1,090 (2,403)

Gross  axle  weight
rating-rear

1,280 (2,822)

Seating capacity

5

Engine

Model No.

6B31

Piston displacement

3.0 L

Transaxle

Model No.

F6AJA

W6AJA

Type

6-speed automatic

Fuel system

Fuel supply system

Multiport fuel injection

00-12

GENERAL

GENERAL DATA AND SPECIFICATIONS

Item

CW6W
XLMYL2M

XLXYL2M/7M

XLXYZL2M/7M

Vehicle
dimension mm
(in)

Overall length

1 4,640 (182.7)

4,640 (182.7)

4,640 (182.7)

Overall width

2 1,800 (70.9)

1,800 (70.9)

1,800 (70.9)

Overall

 height

(unladen)

3 1,680 (66.1)

<Vehicles

 without

roof rail>
1,720 (67.7)
<Vehicles  with  roof
rail>

1,720 (67.7)
<Vehicles  with  roof
rail>

1,680 (66.1)
<Vehicles

 without

roof rail>
1,720 (67.7)
<Vehicles  with  roof
rail>

Wheelbase

4 2,670 (105.1)

2,670 (105.1)

2,670 (105.1)

Tread-front

5 1,540 (60.6)

1,540 (60.6)

1,540 (60.6)

Tread-rear

6 1,540 (60.6)

1,540 (60.6)

1,540 (60.6)

Overhang-front

7 965 (38.0)

965 (38.0)

965 (38.0)

Overhang-rear

8 1,005 (39.6)

1,005 (39.6)

1,005 (39.6)

Ground clearance 9 215 (8.5)

215 (8.5)

215 (8.5)

Vehicle weight
kg (lb)

Curb weight

1,675 (3,692)

1,670 (3,681)

1,735 (3,825)

Gross  vehicle  weight
rating

2,300 (5,071)

2,350 (5,181)

Gross  axle  weight
rating-front

1,090 (2,403)

Gross  axle  weight
rating-rear

1,280 (2,822)

Seating capacity

7

Engine

Model No.

6B31

Piston displacement

3.0 L

Transaxle

Model No.

F6AJA

W6AJA

Type

6-speed automatic

Fuel system

Fuel supply system

Multiport fuel injection

<Vehicles for CANADA>

ZC5019470000

5
2

9

7

4
1

8

3

6

GENERAL

00-13

GENERAL DATA AND SPECIFICATIONS

Item

CW6W
XLSYL3M

XLSYZL3M

XLXYL3M

XLXYZL3M

Vehicle
dimension mm
(in)

Overall length

1 4,640 (182.7)

4,640 (182.7)

4,640 (182.7)

4,640 (182.7)

Overall width

2 1,800 (70.9)

1,800 (70.9)

1,800 (70.9)

1,800 (70.9)

Overall

 height

(unladen)

3 1,680 (66.1)

<Vehicles
without

 roof

rail>
1,720 (67.7)
<Vehicles  with
roof rail>

1,720 (67.7)
<Vehicles  with
roof rail>

1,680 (66.1)
<Vehicles
without

 roof

rail>
1,720 (67.7)
<Vehicles  with
roof rail>

1,720 (67.7)
<Vehicles  with
roof rail>

Wheelbase

4 2,670 (105.1)

2,670 (105.1)

2,670 (105.1)

2,670 (105.1)

Tread-front

5 1,540 (60.6)

1,540 (60.6)

1,540 (60.6)

1,540 (60.6)

Tread-rear

6 1,540 (60.6)

1,540 (60.6)

1,540 (60.6)

1,540 (60.6)

Overhang-front

7 965 (38.0)

965 (38.0)

965 (38.0)

965 (38.0)

Overhang-rear

8 1,005 (39.6)

1,005 (39.6)

1,005 (39.6)

1,005 (39.6)

Ground clearance 9 215 (8.5)

215 (8.5)

215 (8.5)

215 (8.5)

Vehicle weight
kg (lb)

Curb weight

1,615 (3,560)

1,680 (3,703)

1,670 (3,681)

1,735 (3,825)

Gross  vehicle  weight
rating

2,300 (5,071)

2,350 (5,181)

2,300 (5,071)

2,350 (5,181)

Gross  axle  weight
rating-front

1,090 (2,403)

Gross  axle  weight
rating-rear

1,100 (2,425)

Seating capacity

5

7

Engine

Model No.

6B31

Piston displacement

3.0 L

Transaxle

Model No.

F6AJA

W6AJA

F6AJA

W6AJA

Type

6-speed automatic

Fuel system

Fuel supply system

Multiport fuel injection

00-14

GENERAL

GENERAL DATA AND SPECIFICATIONS
