Mitsubishi Outlander XL. Manual - part 108
CENTRAL DOOR LOCKING SYSTEM
CIRCUIT DIAGRAMS
90-129
KEYLESS
ENTRY
RECEIVER
KEYLESS
ENTRY
TRANSMITTER
WIRELESS CONTROL MODULE
: ·AIR CONDITIONING SYSTEM
·BRAKE WARNING LIGHT
·CONTROLLER AREA NETWORK (CAN)
·DAYTIME RUNNING LIGHT
·FOG LIGHT
·FUEL WARNING LIGHT
·GLOVE BOX LIGHT
·HEADLIGHT
·IGNITION KEY REMINDER TONE ALARM
·METER AND GAUGE
·OIL PRESSURE WARNING LIGHT
·REAR WIPER AND WASHER
·SEAT BELT WARNING TONE ALARM
·TAILLIGHT, POSITION LIGHT, LICENSE
PLATE LIGHT AND LIGHTING MONITOR
TONE ALARM
·TURN-SIGNAL LIGHT AND HAZARD
WARNING LIGHT
·WINDSHIELD WIPER AND WASHER
·AIR CONDITIONING SYSTEM
·ANTI-LOCK BRAKING SYSTEM (ABS)
·ANTI-LOCK BRAKING SYSTEM (ABS)
AND ACTIVE SKID CONTROL SYSTEM
(ASC)
·AUTO-CRUISE CONTROL SYSTEM
·BRAKE WARNING LIGHT
·CHARGING SYSTEM
·CONTROLLER AREA NETWORK (CAN)
·DAYTIME RUNNING LIGHT
·DOOR AJAR WARNING TONE ALARM
·ELECTRIC CONTROLLED AWD
·FOG LIGHT
·FUEL WARNING LIGHT
·GLOVE BOX LIGHT
·HEADLIGHT
·HEADLIGHT AUTOMATIC LEVELING
SYSTEM
·HEATED DOOR MIRROR
·HEATED SEAT
·IGNITION KEY REMINDER TONE ALARM
·INVECS-II 6A/T
·METER AND GAUGE
·MFI SYSTEM
·OIL PRESSURE WARNING LIGHT
·REAR WINDOW DEFOGGER
·REAR WIPER AND WASHER
·SEAT BELT WARNING TONE ALARM
·SHIFT LOCK MECHANISM
·SUNROOF
·SUPPLEMENTAL RESTRAINT SYSTEM
(SRS)
·TAILLIGHT, POSITION LIGHT, LICENSE
PLATE LIGHT AND LIGHTING MONITOR
TONE ALARM
·THEFT-ALARM SYSTEM
·TIRE PRESSURE MONITORING SYSTEM
(TPMS)
·TURN-SIGNAL LIGHT AND HAZARD
WARNING LIGHT
·WINDSHIELD WIPER AND WASHER
:
NOTE
WIRE COLOR CODE
B : BLACK LG : LIGHT GREEN G : GREEN L : BLUE W : WHITE Y : YELLOW SB : SKY BLUE
BR : BROWN O : ORANGE GR : GRAY R : RED P : PINK V : VIOLET PU : PURPLE
<VEHICLES WITHOUT KOS>
INTERFACE
CIRCUIT
CAN DRIVE
CIRCUIT
FUSIBLE
LINK
36
IG1
RELAY
ENGINE
COMPARTMENT
RELAY BOX
ETACS-ECU
