ANTI-LOCK BRAKING SYSTEM (ABS)

TSB Revision

CIRCUIT DIAGRAMS

90-317

ETACS-
ECU

INTERFACE
CIRCUIT

CAN DRIVE
CIRCUIT

JOINT
CONNECTOR
(CAN1)

WIRE COLOR CODE
B : BLACK     LG : LIGHT GREEN     G : GREEN     L : BLUE     W : WHITE     Y : YELLOW     SB : SKY BLUE
BR : BROWN     O : ORANGE     GR : GRAY     R : RED     P : PINK     V : VIOLET     PU : PURPLE     SI : SILVER

CPU

RHEOSTAT

CAN
TRANSCEIVER
CIRCUIT

ETACS-ECU

(FUSE     )

12

LED DRIVE
CIRCUIT

COMBINATION
METER

LCD

ABS
BRAKE

ANTI-LOCK BRAKING SYSTEM (ABS) AND ACTIVE STABILITY CONTROL SYSTEM (ASC)

TSB Revision

CIRCUIT DIAGRAMS

90-318

ANTI-LOCK BRAKING SYSTEM (ABS) AND ACTIVE STABILITY

CONTROL SYSTEM (ASC)

M1901021701696

FUSIBLE
LINK

27

FUSIBLE
LINK

26

POWER
SUPPLY

ASC-ECU

SOLENOID VALVE
POWER SUPPLY

MOTOR POWER
SUPPLY

IGNITION
SWITCH (IG1)

IG1
RELAY

·INVECS-II 6A/T
·INVECS-III CVT

·ELECTRONIC
 CONTROLLED AWD
·S-AWC

ANTI-LOCK BRAKING SYSTEM (ABS) AND ACTIVE STABILITY CONTROL SYSTEM (ASC)

TSB Revision

CIRCUIT DIAGRAMS

90-319

ETACS-
ECU

STOPLIGHT
SWITCH

STOPLIGHT
RELAY

POWER
DISTRIBUTION
SYSTEM

FUSIBLE
LINK

34

FUSIBLE
LINK

36

RELAY BOX

ENGINE
COMPARTMENT

THEFT-ALARM
SYSTEM

·SPARE
 CONNECTOR
 (FOR TRAILER
 LIGHTS)
·STOPLIGHT

NOTE

: ·AIR CONDITIONING SYSTEM

·CENTRAL DOOR
 LOCKING SYSTEM
·DAYTIME RUNNING LIGHT (DRL)
·DOME LIGHT, LUGGAGE
 COMPARTMENT
 LIGHT AND IGNITION KEY
 HOLE ILLUMINATION LIGHT
·FOG LIGHT
·GLOVE BOX LIGHT
·HEADLIGHT
·HEATED DOOR MIRROR
·HEATED SEAT
·IGNITION KEY
 REMINDER TONE ALARM
 <VEHICLES WITH KOS>
·IMMOBILIZER SYSTEM
·INVECS-II 6A/T

·INVECS-III CVT
·KEYLESS OPERATING SYSTEM (KOS)
·REAR WINDOW DEFOGGER
·REAR WIPER AND WASHER
·SEAT BELT WARNING TONE ALARM
·SHIFT LOCK MECHANISM
·SUNROOF
·SUPPLEMENTAL RESTRAINT
 SYSTEM (SRS)
·TAILLIGHT, POSITION LIGHT, REAR SIDE
 MARKER LIGHT, LICENSE PLATE LIGHT
 AND LIGHTING MONITOR TONE ALARM
·THEFT-ALARM SYSTEM
·TIRE PRESSURE MONITORING
 SYSTEM (TPMS)
·TURN-SIGNAL LIGHT AND HAZARD
 WARNING LIGHT
·WINDSHIELD WIPER AND WASHER

WIRE COLOR CODE
B : BLACK     LG : LIGHT GREEN     G : GREEN     L : BLUE     W : WHITE     Y : YELLOW     SB : SKY BLUE
BR : BROWN     O : ORANGE     GR : GRAY     R : RED     P : PINK     V : VIOLET     PU : PURPLE     SI : SILVER

ANTI-LOCK BRAKING SYSTEM (ABS) AND ACTIVE STABILITY CONTROL SYSTEM (ASC)

TSB Revision

CIRCUIT DIAGRAMS

90-320

ANTI-LOCK BRAKING SYSTEM (ABS) AND ACTIVE STABILITY CONTROL SYSTEM (ASC)



(CONTINUED)

ENGINE CONTROL
MODULE

INPUT SIGNAL

ACCELERATOR
PEDAL POSITION
SENSOR

SOLENOID
VALVE POWER
SUPPLY

SOLENOID VALVE

HYDRAULIC UNIT

JOINT
CONNECTOR
(CAN3)

JOINT CONNECTOR
(CAN2)
