MANUAL A/C DIAGNOSIS TSB Revision HEATER, AIR CONDITIONING AND VENTILATION 55A-7 STEP 3. Check the A/C compressor clutch relay continuity. Follow the table below to check the A/C compressor clutch Q: Is the A/C compressor clutch relay in good condition? YES : Go to Step 4. Step 10. STEP 4. Check the A/C compressor clutch operation. Connect the positive battery terminal to the air conditioning heard? 10. BATTERY VOLTAGE TESTER SPECIFIED Not applied 4 − 5 Open circuit • Connect terminal 3 to the positive battery terminal • Connect terminal 1 to the negative battery terminal 4 − 5 Less than 2 AC204715 3 1 4 5 AE A/C BATTERY ACX01440AB |
