TSB Revision DIAGNOSTIC TROUBLE CODE PROCEDURES 13Ac-505 STEP 8. Check for leaks in the evaporator line hose F. 13B, Fuel Tank (2) Disconnect hose F from the evaporative emission canister and plug hose F securely. (3) Disconnect hose G from the evaporative emission canister side, and connect a hand vacuum pump. (4) Apply vacuum with the hand vacuum pump and confirm that the vacuum holds. (5) Disconnect the hand vacuum pump and connect hose F and G. Q: Does hose F hold vacuum? YES : Go to Step 9. protector. (Refer to GROUP 13B, Fuel Tank STEP 9. Check for leaks in the evaporative emission Fuel Tank (2) Perform a leakage test with a hand vacuum pump on each hose from hose G to N. Q: Does the hoses hold vacuum? YES : Go to Step 10. tank filler tube and the fuel tank filler tube protector. ). Go to Step 18. AC101767 AC HOSE F HOSE G AC102673 AC HOSE G HOSE L HOSE M HOSE N AC102646 AC HOSE K HOSE I HOSE H HOSE J |
