REAR AIR CONDITIONING DIAGNOSIS TSB Revision HEATER, AIR CONDITIONING AND VENTILATION 55A-91 STEP 25. Measure the resistance at rear heater switch the resistance at the wiring harness side. (2) Measure the resistance value between terminal 1 and ground. • 2 ohm or less Q: Does the measured resistance value correspond with this range? AC204193 CONNECTORS : E-17, E-21, E-22 AC E-17, E-21, E-22 E-17 <VEHICLES WITH REAR COOLER> HARNESS SIDE 1 2 10 11 5 13 6 14 12 4 9 3 AC204738 CM HARNESS SIDE : E-17, E-21, E-22 1 2 10 11 5 13 6 14 12 4 9 3 |
