MULTIPORT FUEL INJECTION (MFI) DIAGNOSIS TSB Revision MULTIPORT FUEL INJECTION (MFI) <2.4L ENGINE> 13A-661 STEP 12. Measure the fuel tank differential pressure (1) Remove the rear seat cushion assembly (Refer to GROUP 52A, Rear Seat (2) Remove the hole cover (RH). (3) Disconnect fuel tank differential pressure sensor connector D-23. (4) Use special tool MB991658 to connect terminals 1,2 and 3 of the fuel tank differential pressure sensor connector D-23. (5) Turn the ignition switch to the "ON" position. • The voltage should measure 0.5 volt or less. (7) Turn the ignition switch to the "LOCK" (OFF) position. YES : Go to Step 13. AC306089 HOLE COVER AB AC305266 CONNECTOR: D-23 AB D-23 (B) AC306775 AB MB991658 1 2 3 D-23 (B)
|
