AUTOMATIC TRANSAXLE DIAGNOSIS TSB Revision AUTOMATIC TRANSAXLE 23A-99 STEP 6. Measure the PCM output voltage to the speed (1) Disconnect all the connectors from the PCM. (2) Connect special tool MB991923 (check harness) between the PCM and the body-side harness connector. (3) Turn the ignition switch to the "ON" position. AC306248AE B-22 CONNECTOR: B-22 PCM AIR JAE 94 98 107 103 112 91 100 109 101102 106 110 105 111 97 92 96 93 104 113 108 95 99 AC209793AH SPECIAL TOOL 23-PIN CONNECTOR 104 96 94 95 93 92 91 99 98 97 103 102 101 100 108 107 106 105 113 112 111 110 109 PCM MB991923 BODY SIDE B-22 |
