ON-VEHICLE SERVICE TSB Revision WHEEL AND TIRE 31-7 ON-VEHICLE SERVICE TIRE INFLATION PRESSURE CHECK M1311000900323 NOTE: For information on tire inflation pressure, refer to the TIRE WEAR CHECK M1311001000345 Measure the tread depth of the tires. Minimum limit: 1.6 mm (0.06 inch) If the remaining tread depth is less than the minimum limit, WHEEL RUNOUT CHECK M1311001100364 Jack up the vehicle so that the wheels are clear of the floor. Limit: If wheel runout exceeds the limit, replace the wheel. WHEEL AND TIRE INSTALLATION SERVICE POINT M1311001300302 Tighten the wheel nuts to the specified torque. Tightening torque: 98 ± 10 N⋅m (73 ± 7 ft-lb) ITEM STEEL WHEEL ALUMINUM Radial runout 1.2 mm (0.05 inch) or less 1.0 mm (0.04 inch) Lateral 1.2 mm (0.05 inch) 1.0 mm (0.04 inch) ACX00651AB LATERAL RADIAL |
