MULTIPORT FUEL INJECTION (MFI) DIAGNOSIS TSB Revision MULTIPORT FUEL INJECTION (MFI) <3.8L ENGINE> 13B-837 STEP 3. Measure the power supply voltage at throttle CAUTION Because it is not possible to distinguish the top and the harness side. (2) Measure the voltage between terminal No. 1 and ground. • Voltage should be battery positive voltage. Q: Is battery positive voltage (approximately 12 volts) present? connector for damage, and repair or replace as . If intermediate connector A-13 is in good condition, repair it because of open circuit or 1 2 3 4 AK303175 CONNECTOR: B-14X FRONT OF VEHICLE B-14X AB HARNESS RELAY BOX AK303186AB B-14X HARNESS |
