Mitsubishi Galant (2004+). Manual - part 101
MANUAL AIR CONDITIONING SYSTEM <MIDDLE>
TSB Revision
CIRCUIT DIAGRAMS
90-163
·CENTRAL DOOR
LOCKING SYSTEM
·CONTROLLER AREA
NETWORK (CAN)
·FRONT DOME LIGHT,
REAR DOME LIGHT,
TRUNK LIGHT AND
IGNITION KEY HOLE
ILLUMINATION LIGHT
·WINDSHIELD WIPER
AND WASHER
IGNITION
SWITCH (ACC)
POWER SUPPLY
RELAY
BOX
JOINT
CONNECTOR (2)
A/C-ECU
WIRE COLOR CODE
B : BLACK LG : LIGHT GREEN G : GREEN L : BLUE
BR :BROWN O : ORANGE GR : GRAY R : RED W : WHITE
SB : SKY BLUE P : PINK Y : YELLOW V : VIOLET
WINDSHIELD WIPER
AND WASHER
AUDIO SYSTEM
·CENTRAL DOOR
LOCKING SYSTEM
·CONTROLLER
AREA NETWORK
(CAN)
·FRONT DOME LIGHT,
REAR DOME LIGHT,
TRUNK LIGHT AND
IGNITION KEY HOLE
ILLUMINATION LIGHT
·REMOTE
CONTROLLED
MIRROR
