ENGINE COMPARTMENT

TSB Revision

CONFIGURATION DIAGRAMS

80A-5

AC304352AB

11

12

13

A-04

A-05X
A-06X
A-10X
A-11X
A-12X

A-13

A-14

A-15X
A-16X

A-17

A-18

A-19

A-20

A-21

A-22

A-23

A-25

A-26

A-24
A-37

A-21

(2-B)

HEADLIGHT (HIGH: LH) <4-BULB
TYPE>

A-22

(2-B)

FOG LIGHT (LH)

A-23

(2-Y)

FRONT IMPACT SENSOR (LH)

A-24

(2-GR)

CONDENSER FAN MOTOR <3.8L
ENGINE>

A-25

(2-BR)

AMBIENT TEMPERATURE SENSOR

A-26

(2-GR)

RADIATOR FAN MOTOR

A-27

(2-Y)

FRONT IMPACT SENSOR (RH)

A-28

(2-B)

FOG LIGHT (RH)

A-29

(2)

WINDSHIELD WASHER MOTOR

A-30

(2-B)

A/C PRESSURE SENSOR

A-31

(2-B)

HEADLIGHT (HIGH: RH) <4-BULB
TYPE>

A-32

(2-BR)

HEADLIGHT (LOW: RH) <4-BULB
TYPE>

A-33

(3-GR)

HEADLIGHT (RH) <2-BULB TYPE>

A-34

(3-GR)

FRONT COMBINATION LIGHT (RH)

A-35

(2)

FRONT SIDE MARKER LIGHT (RH)

A-36

(1-B)

HORN

A-37

(2-B)

CONDENSER FAN MOTOR <2.4L
ENGINE>

ENGINE AND TRANSAXLE <2.4L ENGINE>

TSB Revision

CONFIGURATION DIAGRAMS

80A-6

ENGINE AND TRANSAXLE <2.4L ENGINE>

M1801000400612

AC304354

Connector
symbol

-01
thru
-38

B

AB

CONNECTOR COLOR
CODE
B: BLACK
BR: BROWN
G: GREEN
GR: GRAY
L: BLUE
NONE: MILK WHITE
O: ORANGE
R: RED
V: VIOLET
Y: YELLOW

B-01

B-05

B-02

B-03

CONTROL
WIRING
HARNESS

GROUNDING
CABLE

B-38

B-37

B-31

B-28

B-30

B-01

(2-GR)

INJECTOR 1

B-02

(3-B)

MANIFOLD ABSOLUTE PRESSURE
SENSOR

B-03

(2-GR)

INJECTOR 3

B-05

(2-B)

EVAPORATIVE EMISSION PURGE
SOLENOID

B-06

(6-B)

THROTTLE BODY ASSEMBLY

B-07

(2-GR)

BRAKE FLUID LEVEL SWITCH

B-10

(4-GR)

MASS AIRFLOW SENSOR

B-14X (4)

THROTTLE ACTUATOR CONTROL
MOTOR RELAY

B-16X (4)

A/T CONTROL RELAY

B-17X (4)

MFI RELAY

B-18X (4)

A/C COMPRESSOR CLUTCH RELAY

B-19

(18-B)

POWERTRAIN CONTROL MODULE

B-20

(23)

POWERTRAIN CONTROL MODULE

B-21

(33-B)

POWERTRAIN CONTROL MODULE

B-22

(23-B)

POWERTRAIN CONTROL MODULE

ENGINE AND TRANSAXLE <2.4L ENGINE>

TSB Revision

CONFIGURATION DIAGRAMS

80A-7

AC304355AB

9

10

14

B-27

B-06

B-07

B-33

B-34

B-10

B-14X
B-16X
B-17X
B-18X

B-19

B-20

B-21

B-22

B-23

B-35

B-36

B-29

B-23

(33)

POWERTRAIN CONTROL MODULE

B-27

(2-GR)

INJECTOR 4

B-28

(1-B)

A/C COMPRESSOR ASSEMBLY

B-29

(1-B)

ENGINE OIL PRESSURE SWITCH

B-30

(2-GR)

INJECTOR 2

B-31

(1-B)

POWER STEERING PRESSURE
SWITCH

B-33

(2-B)

ENGINE OIL CONTROL VALVE

B-34

(1-B)

ENGINE OIL PRESSURE SWITCH
(FOR ENGINE OIL CONTROL
VALVE)

B-35

(4-B)

CYLINDER 2, 3 HEATED OXYGEN
SENSOR (REAR)

B-36

(4-GR)

CYLINDER 2, 3 HEATED OXYGEN
SENSOR (FRONT)

B-37

(4-GR)

CYLINDER 1, 4 HEATED OXYGEN
SENSOR (FRONT)

B-38

(4-B)

CYLINDER 1, 4 HEATED OXYGEN
SENSOR (REAR)

ENGINE AND TRANSAXLE <2.4L ENGINE>

TSB Revision

CONFIGURATION DIAGRAMS

80A-8

ENGINE AND TRANSAXLE <2.4L ENGINE> (CONTINUED)

AC304354

Connector
symbol

-101
thru
-120

B

CONTROL
WIRING
HARNESS

GROUNDING
CABLE

AC

B-101

B-120

B-105

B-102

B-118

B-119

B-116

B-116

B-115

CONNECTOR COLOR
CODE
B: BLACK
BR: BROWN
G: GREEN
GR: GRAY
L: BLUE
NONE: MILK WHITE
O: ORANGE
R: RED
V: VIOLET
Y: YELLOW

B-101 (3-GR)

IGNITION COIL 1

B-102 (3-GR)

IGNITION COIL 3

B-104 (2-B)

ENGINE COOLANT TEMPERATURE
SENSOR

B-105 (6-GR)

EXHAUST GAS RECIRCULATION
VALVE

B-106 (3-B)

CAMSHAFT POSITION SENSOR

B-107 (3-GR)

OUTPUT SHAFT SPEED SENSOR

B-108 (10-GR) A/T CONTROL SOLENOID VALVE

ASSEMBLY

B-109 (3-B)

INPUT SHAFT SPEED SENSOR
