Mitsubishi Space Star. Manual - part 1

00-1

GENERAL

CONTENTS

HOW TO USE THIS MANUAL

2

. . . . . . . . . . . . . .

Model Indications

2

. . . . . . . . . . . . . . . . . . . . . . . . . . . . .

VEHICLE IDENTIFICATION

2

. . . . . . . . . . . . . . . . . .

Models

2

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Model code

3

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

MAJOR SPECIFICATIONS

4

. . . . . . . . . . . . . . . . . .

GENERAL  – How To Use This Manual/Vehicle Identification

00-2

HOW TO USE THIS MANUAL

MODEL INDICATIONS

The following abbreviations are used in this manual for identification of model types.
MPI: Indicates the multi point fuel injection.
GD-D: Indicates the direct injection diesel.
GDI: Indicates the gasoline direct injection.
M/T: Indicates the manual transmission, or models equipped with the manual transmission.
A/T: Indicates the automatic transmission, or models equipped with the automatic transmission.
A/C: Indicates the air conditioner.

VEHICLE IDENTIFICATION

MODELS

Model code

Engine model

Transmission model

Fuel supply system

DG1A

LNDEL6/R6

4G13 MPI (1,299 mL)

F5MR1 <5M/T>

MPI
(Multi Point Fuel Injection)

LNJEL6/R6

(Multi Point Fuel Injection)

LNPEL6/R6

DG4A

LNDFL6/R6

F9Q1 (1,870 mL)

F5MV1 <5M/T>

DI-D
(Direct Injection Diesel)

LNJFL6/R6

(Direct Injection Diesel)

LNPFL6/R6

DG5A

LNDCL6

4G93 GDI (1,834 mL)

F5M42 <5M/T>

GDI
(Gasoline Direct Injection)

LNJCL6/R6

(Gasoline Direct Injection)

LRJCL6/R6

F4A42
<INVECS-

II

 4A/T with

Sports Mode>

LNPCL6/R6

F5M42 <5M/T>

LRPCL6/R6

F4A42
<INVECS-

II

 4A/T with

Sports Mode>

GENERAL  – Vehicle Identification

00-3

MODEL  CODE

No.

Items

Contents

1

Development

DG: MITSUBISHI SPACE STAR

2

Engine type

1:

1,299 mL petrol engine

2

Engine ty e

1:

1,299 mL  etrol engine

4:

1,870 mL diesel engine

5

1 834

L

t l

i

,

g

5:

1,834 mL petrol engine

3

Sort

A:

Passenger car

4

Body style

L:

5-door

5

Transmission type

N:

5-speed manual
transmission

R:

4-speed automatic
transmission

6

Trim level

D:

Family

6

Trim level

D:

Family

J:

Comfort

P

S

t

P:

Sport

7

Specification engine
feature

E:

MPI

F:

DI-D

C:

GDI

8

Steering wheel
location

L:

Left hand

R:

Right hand

9

Destination

6:

For Europe

GENERAL  – Major Specifications

00-4

MAJOR SPECIFICATIONS

1

2

3

3

*1

4

5

6

7

8

9

Items

DG1A

DG4A

Items

LNDEL6
/R6

LNJEL6
/R6

LNPEL6
/R6

LNDFL6
/R6

LNJFL6
/R6

LNPFL6
/R6

Vehicle
di

i

Overall length

1

4,030

dimensions
mm

Overall width

2

1,715

mm

Overall height
(unladen)

3

1,515,
1,555

*1

Wheelbase

4

2,500

Track-front

5

1,475

Track-rear

6

1,470

Overhang-front

7

835

Overhang-rear

8

695

Ground clear-
ance (unladen)

9

155

Vehicle

i h k

Kerb weight

1,158

1,170

1,173

1,248

1,260

1,258

weight kg

Max. gross vehicle
weight

1,655

1,730

Max. axle weight
rating-front

855

920

Max. axle weight
rating-rear

830

850

Seating capacity

5

Engine

Model No.

4G13

F9Q1

g

Total displacement
mL

1,299

1,870

Transmission

Model No.

F5MR1

F5MV1

Type

5 speed-manual

Fuel system

Fuel supply system

Multi Point Fuel Injection

Direct Injection Diesel

NOTE:
*

1

: Vehicles with roof rails
