DIAGNOSIS <TC-SST> TSB Revision TWIN CLUTCH- SPORTRONIC SHIFT TRANSMISSION (TC-SST) 22C-169 STEP 4. Replace the mechatronic assembly, and check if (2) Drive in the 6th gear. YES : Replace the transaxle assembly. (Refer to .) NO : This diagnosis is complete. DTC P182D: Shift Fork Position Sensor 3 System (Neutral) CAUTION • If there is any problem in the CAN bus lines, an incorrect diagnostic trouble code may be • Whenever the ECU is replaced, ensure that the CAN bus lines are normal. . DIAGNOSTIC FUNCTION TC-SST-ECU checks that the shift fork position sen- . DESCRIPTIONS OF MONITOR METHODS The shift fork position sensor 3 is determined to be . MONITOR EXECUTION • Continuous . MONITOR EXECUTION CONDITIONS Other Monitor (There is no temporary DTC stored in memory for the item monitored below) • P182A: Shift fork position sensor 3 system (Volt- age low range out) • P182B: Shift fork position sensor 3 system (Volt- age high range out) • P182C: Shift fork position sensor 3 system (Out- put range out) • P182E: Shift fork position sensor 3 system (Poor performance) • P1844: Shift fork 3 malfunction ment • P1855: Shift fork 3 or 4 opposite direction move- ment • P1858: Even number gear axle interlock Sensor (The sensor below is determined to be normal) • Not applicable . |
