ENGINE CONTROL MODULE (ECM)
TSB Revision
MULTIPORT FUEL INJECTION (MFI)
13A-889
REMOVAL SERVICE POINT
.
<<A>> BREAK-OFF BOLTS REMOVAL <VEHI-
CLES FOR CANADA>
1. Drill in the break-off bolt a hole deep enough for the tap to
stand.
2. Remove the break-off bolt with a left-hand tap.
INSTALLATION SERVICE POINTS
.
>>A<< BREAK-OFF BOLTS INSTALLATION
<VEHICLES FOR CANADA>
Tighten until the head of break-off bolt is broken off.
.
>>B<< INITIALIZATION OPERATION
Turn the ignition switch to the "ON" and then to "LOCK" (OFF)
position and hold it for at least 10 seconds.
Removal steps
>>
B
<<
•
Initialization operation (only at
installation)
<<
A
>>
>>
A
<<
1.
Break-off bolts <vehicles for
Canada>
2.
ECM connector cover <vehicles
for Canada>
3.
ECM connector connection
4.
ECM stay
5.
ECM and ECM bracket assembly
<<
A
>>
>>
A
6.
Break-off bolts <vehicles for
Canada>
7.
ECM bracket
8.
ECM
Removal steps (Continued)
AC609908AB
Break-off bolt
ECM
Reverse screw tap
