DIAGNOSIS TSB Revision CONTROLLER AREA NETWORK (CAN) 54C-221 STEP 9. Check the wiring harness between joint connector resistance at the wiring harness side of joint connector (2) Measure the resistance between joint connector (CAN1) terminal 5 and body ground. OK: 1 kΩ or more (3) Measure the resistance between joint connector (CAN1) terminal 16 and body ground. OK: 1 kΩ or more Q: Do all the resistances measure 1 kΩ or more? YES (vehicles without satellite radio) : Go to Step 12. AC608179 TEST Harness side: C-105 CM AC608179 Harness side: C-105 CN TEST |
