TROUBLESHOOTING <ACD> MANUAL TRANSMISSION (FF) 22A-59 STEP 12. Measure the voltage at longitudinal (1) Disconnect the longitudinal G-sensor connector, and connect special tool harness set (MB991348) (2) Turn the ignition switch to the ON position. (3) Measure the voltage between terminal No.2 and earth. OK: When vehicle is stationary (level): 2.4 − 2.6 V When vehicle is being driven: 3.4 − 3.6 V Q: Is the check result normal? YES : Go to Step 13. NO : Replace the G-sensor. AC103662AL MB991348 Connector: D-38 Label Label |
