SUPPLEMENTAL RESTRAINT SYSTEM (SRS)

CIRCUIT DIAGRAMS

90-211

CONNECTOR
LOCK SWITCH

NOTE
   : CONNECTOR
     COUPLED
     : ON
     CONNECTOR
     UNCOUPLED
     : OFF

CONNECTOR LOCK SWITCH

SRS-ECU

CONNECTOR LOCK
DETECTION CIRCUIT

WARNING LAMP
DRIVE CIRCUIT

AIR BAG
DRIVE CIRCUIT

AIR BAG
DRIVE CIRCUIT

CONNECTOR
LOCK
SWITCH

CONNECTOR
LOCK
SWITCH

CONNECTOR
LOCK SWITCH

CONNECTOR
LOCK SWITCH

SEAT BELT
PRE-TENSIONER (LH)

SEAT BELT
PRE-TENSIONER (RH)

Wire colour code
B : Black     LG : Light green     G : Green     L : Blue    W : White
Y : Yellow     SB : Sky blue     BR : Brown    O : Orange
GR : Grey     R : Red     P : Pink     V : Violet    PU : Purple

SUPPLEMENTAL RESTRAINT SYSTEM (SRS)

CIRCUIT DIAGRAMS

90-212

SUPPLEMENTAL RESTRAINT SYSTEM (SRS) <RH drive vehicles> (CONTINUED)

SRS-ECU

MICROCOMPUTER

INTERFACE CIRCUIT

FRONT IMPACT
SENSOR (LH)

FRONT IMPACT
SENSOR (RH)

DIAGNOSIS
CONNECTOR

M.U.T.-II/III
INTERFACE
CIRCUIT

FUSIBLE
LINK

1

FRONT SIDE

CRASH DETECTION DOOR UNLOCK
SIGNAL PROCESS CIRCUIT

CENTRAL DOOR
LOCKING SYSTEM

SUPPLEMENTAL RESTRAINT SYSTEM (SRS)

CIRCUIT DIAGRAMS

90-213

NOTES

ACD AND AYC

CIRCUIT DIAGRAMS

90-214

ACD AND AYC

ACD AND AYC <LH drive vehicles>

M1901023600089

4WD-
ECU

BATTERY

RELAY
BOX

RELAY
BOX

BATTERY

STOP
LAMP
SWITCH

IGNITION
SWITCH (IG2)

BATTERY
BACK-UP

POWER
SOURCE

·HEADLAMP
·HEADLAMP
 LEVELLING SYSTEM
·REAR FOG LAMP
·TAIL LAMP,
 POSITION LAMP,
 LICENCE PLATE
 LAMP  AND LIGHTING
 MONITOR BUZZER
·TURN-SIGNAL LAMP
 AND HAZARD WARNING
 LAMP
·WINDSHIELD WIPER
 AND WASHER

ANTI-SKID BRAKING
SYSTEM (ABS)

STOP LAMP
