Inspection Connector / Fusible Link and
Fuse

SINGLE PART
INSTALLATION POSITION

 –

C-20

INSPECTION CONNECTOR

Engine speed
check connector

Fuel pump
check connector

FUSIBLE LINK AND FUSE

<Vehicles with AYC
(vehicles without ABS)>

Fusible link

<Vehicles with AYC
(vehicles with ABS)>

Fusible link

SINGLE PART INSTALLATION POSITION –

Earth Cable / Earth

C-21

EARTH CABLE

EARTH

C-22

NOTES

CIRCUIT DIAGRAM –

Centralized Junction

C-23

CIRCUIT DIAGRAM

CENTRALIZED JUNCTION

CENTRALIZED RELAY

Connector No.

Name

Connector No.

Name

A-82X

Radiator fan motor relay (LO)

A-113X

Condenser fan motor relay (LO)

A-112X

Radiator fan motor relay (HI)

A-114X

Condenser fan motor relay (HI)

Relay box in engine compartment

(A/C relay box)
