IMMOBILIZER SYSTEM

CHASSIS ELECTRICAL

54A-39

DATA LIST REFERENCE TABLE

M1541104000092

CHECK ETACS-ECU (IMMOBILIZER-ECU)

M1541104100163

TERMINAL VOLTAGE CHECK TABLE

Refer to

P.54A-553

.

ON-VEHICLE SERVICE

HOW TO REGISTER ENCRYPTED CODE

M1541104300510

For details of the key registration procedure, refer to the ID registration manual.
KEY SUPPLY UNIT

KEY SUPPLY UNIT LIST FOR OTHER THAN INDIVIDUAL KEY

Item No.

Inspection item

Inspection
requirement

Normal condition

1

Memorized transponder keys

−

Number of registered ignition keys

Ignition key <single unit> (A: without transmitter,
B: with transmitter)

AC503862

A

B

AB

Full service key set (A: without transmitter, B:
with transmitter) <LHD (Except single cab) >

Full service key set (A: without transmitter, B:
with transmitter) <RHD (Except single cab) >

AC805739

B

A

AB

AC805740

B

A

AB

IMMOBILIZER SYSTEM

CHASSIS ELECTRICAL

54A-40

Full service key set (A: without transmitter, B:
with transmitter) <LHD (Double cab-M/T-Europe-
rear body less optional)>

Full service key set <LHD (Single cab, Double
cab-low price optional) >

Full service key set <RHD (Single cab) >

Full service key set <LHD (Single cab-rear body
less optional)>

Full service key set <RHD (Single cab-rear body
less optional)>

Steering lock service key set (A: without
transmitter, B: with transmitter)

Door service key set (A: without transmitter, B:
with transmitter)

Door service key set (A: without transmitter, B:
with transmitter) <Dead lock>

AC805738

B

A

AB

AC805742

AC805744

AC805741

AC805743

AC511649

B

A

AB

AC805721

B

A

AB

AC805720

B

A

AB

COMBINATION METER

CHASSIS ELECTRICAL

54A-41

REMOVAL AND INSTALLATION

M1541106900198

CAUTION

When the ETACS-ECU is replaced, refer to the ID Code Registration Judgment Table

P.54A-39

 and

register the each ID code.

COMBINATION METER

SERVICE SPECIFICATIONS

M1540200200742

Glove box service key set (A: without transmitter,
B: with transmitter)

Filler cap service key set (A: without transmitter,
B: with transmitter) <Vehicles without rear body>

AC511650

B

A

AB

AC511655

B

A

AB

Item

Standard
value

Limit

Speedometer indicating tolerance km/h
<Speedometer to display km/h only>

20

20.0

− 24.0

−

40

40.0

− 44.0

−

80

80.5

− 85.5

−

120

121.5

− 127.5

−

160

162.5

− 169.5

−

Speedometer indicating tolerance km/h
(mph) <Speedometer to display MPH and
km/h>

20 (10)

20.0

− 24.0

(10.0

− 12.5)

−

40 (25)

40.0

− 44.0

(25.0

− 27.5)

−

80 (50)

80.5

− 85.5

(50.3

− 53.5)

−

120 (75)

121.5

− 127.5

(76.0

− 80.0)

−

160 (100)

162.5

− 169.5

(101.5

− 106.0)

−

The speedometer needle fluctuation km/h (Vehicle speed is 35 km/h or more)

−

± 3

COMBINATION METER

CHASSIS ELECTRICAL

54A-42

SEALANT

M1540207800013

Tachometer indicating tolerance r/min
The value in parentheses is a reference
value.

700

700

± 100

−

(2,000)

(2,000

± 100)  −

3,000

3,000

± 150

−

(4,000)

(4,000

± 200)

−

5,000

5,000

± 250

−

Fuel gauge unit resistance

Ω

Stopper position "F"

13.0

± 1

−

Stopper position "E"

120.0

± 1

−

Fuel gauge unit float height mm

Stopper position "F"

35.0

± 3

−

Stopper position "E"

254.7

± 3

−

Engine coolant temperature gauge unit
resistance

Ω

The value in parentheses is a reference
value.

50

°C

239

−

(83

°C)

(70.2)

−

(105

°C)

(34.9)

−

122

°C

21.5

−

Item

Standard
value

Limit

Item

Specified sealant

Remark

Engine coolant temperature gauge unit

3M ATD Part No.8660 or equivalent

Semi-drying sealant
