TROUBLESHOOTING SUPPLEMENTAL RESTRAINT SYSTEM (SRS) 52B-235 disconnect the connector. AC801564 Section C-155 Harness side connectors Cable tie Terminal 7 mm or more AG Short spring A A CAUTION Insert an insulator such as a cable tie to a depth between terminals 51, 52 and the short spring to AC800962 CC C-155 Harness side CAUTION Do not insert a test probe into the terminal from harness side connector terminals 51, 52 and OK: Open circuit Q: Is the check result normal? YES : Go to Step 3. NO : Repair the harness wire between SRS-ECU STEP 3. Check whether the diagnosis code is Q: Is diagnosis code B1605 set? YES : ). NO : An intermittent malfunction is suspected |
