T–100
AIR BAG SYSTEM
B2228
19
11
Driver-side air bag module (inflator No.2) system
circuit short to ground
B2229
21
10
Passenger-side air bag module (inflator No.2)
system circuit short to ground
B2230
19
11
Driver-side air bag module (inflator No.2) system
circuit short to power supply
B2231
21
10
Passenger-side air bag module (inflator No.2)
system circuit short to power supply
B2232
19
11
Driver-side air bag module (inflator No.2) system
resistance high
B2233
21
10
Passenger-side air bag module (inflator No.2)
system resistance high
B2234
19
11
Driver-side air bag module (inflator No.2) system
resistance low
B2235
21
10
Passenger-side air bag module (inflator No.2)
system resistance low
B2296
42
9
Crash zone sensor system (communication error,
sensor internal circuit abnormal)
B2444
43
8
Driver-side side air bag sensor system (sensor
internal circuit abnormal)
B2445
44
7
Passenger-side side air bag sensor system
(sensor internal circuit abnormal)
B2477
54
5
Configuration error
B2773
24
17
Driver-side curtain air bag module system
resistance low
B2774
Driver-side curtain air bag module system
resistance high
B2775
Driver-side curtain air bag module system circuit
short to ground
B2776
Driver-side curtain air bag module system circuit
short to power supply
DTC
Malfunction location
WDS or
equivalent
Air bag system warning light
Flashing pattern
Priority
ranking
