Lexus NX350h (2022 year). Manual in english

Press and hold the remote control transmitter button until the HomeLink

indicator

light changes from slowly flashing orange to rapidly flashing green (rolling code) or
continuously lit green (fixed code), then release the button.

●

Programming an entry gate (for U.S.A. owners)/Programming a device in the
Canadian market:
Press and release the remote control transmitter button at 2 second intervals, re-
peatedly, until the HomeLink

indicator light changes from slowly flashing (orange)

to rapidly flashing (green) (rolling code) or continuously lit (green) (fixed code).

Test the HomeLink

operation by pressing the newly programmed button and

observing the indicator light:

●

HomeLink

indicator light illuminates: Programming of a fixed code device has

completed. The garage door or other device should operate when a HomeLink

button is pressed and released.

●

HomeLink

indicator light flashes rapidly: The garage door opener motor or other

device is equipped with a rolling code. To complete programming, firmly press and
hold the HomeLink

button for 2 seconds then release it.

●

If the garage door or other device does not operate, proceed to

Repeat the steps above to program another device for any of the remaining
HomeLink

buttons.

Programming a rolling code system

Two or more people may be necessary to complete rolling code programming.

Locate the “Learn” or “Smart” button on the
garage door opener motor in the garage.

This button can usually be found where the hang-
ing antenna wire is attached to the unit. The name
and color of the button may vary by manufacturer.
Refer to the owner's manual supplied with the
garage door opener motor for details.

Press and release the “Learn” or “Smart” but-
ton.

Perform

within 30 seconds after performing

2-3. Parking the vehicle

186

Press and hold the desired HomeLink

but-

ton (inside the vehicle) for 2 seconds and re-
lease it. Repeat this sequence (press/hold/
release) up to 3 times to complete program-
ming.

If the garage door opener motor operates when
the HomeLink

button is pressed, the garage

door opener motor recognizes the HomeLink

signal.

2-way communication with a garage door and its performance

When enabled, 2-way communication allows you to check the status of the open-
ing and closing of a garage door through indicators in your vehicle.
2-way communication is only available if the garage door opener motor used is a
compatible device.
To check device compatibility, refer to

www.HomeLink.com

Enable 2-way communication with a garage door

Within 5 seconds after programming the garage door opener has been com-
pleted, if the garage door opener motor is trained to HomeLink

, both garage

door operation indicators will flash rapidly green and the light on the garage
door opener motor will blink twice, indicating that 2-way communication is
enabled.

If the indicators do not flash, perform

and

within the first 10 presses of the

HomeLink

button after programming has been completed.

Press a programmed HomeLink

button to operate a garage door.

Within 1 minute of pressing the HomeLink

button, after the garage door

operation has stopped, press the “Learn” or “Smart” button on the garage door
opener motor.

▶

Vehicles with auto anti-glare

inside rear view mirror

▶

Vehicles with Digital Rearview

Mirror

2-3. Parking the vehicle

187

Driving the v

ehicle

Within 5 seconds of the establishment of 2-way communication, both garage door
operation indicators will flash rapidly in green. Additionally, the light on the garage door
opener motor will blink twice, indicating that 2-way communication is enabled.

Operate the HomeLink

This function is only available if the garage door opener motor used is a compatible
device. To check device compatibility, refer to

www.HomeLink.com

▶

Vehicles with auto anti-glare inside rear view mirror

Opening

Closing

▶

Vehicles with Digital Rearview Mirror

Opening

Closing

Press the appropriate HomeLink

button.

The HomeLink

indicator light will turn on. The status

of the opening and closing of a garage door is shown
by the indicators as follows.

●

Orange (flashing): Currently opening/closing

●

Green: Opening/closing has completed

●

Red (flashing): Feedback signals cannot be received

INFORMATION

●

The indicators can operate within approximately 820 ft. (250 m) of the garage door.
However, if there are obstructions between the garage door and the vehicle, such as
houses and trees, feedback signals from the garage door may not be received.

●

To recall the previous door operation status, press and release either HomeLink

buttons

and

(vehicles with auto anti-glare inside rear

view mirror),

and

(vehicles with Digital Rearview Mirror),

simultaneously.
The last recorded status will be displayed for 3 seconds.

2-3. Parking the vehicle

188

Reprogram the HomeLink

When the following procedure is performed, buttons which already have devices
registered to them can be overwritten:

Press and hold the desired HomeLink

button.

When the HomeLink® indicator starts flashing orange, release the Home-
Link

button.

Press and release the HomeLink

button you want to program and check that

the HomeLink

indicator light flashes orange.

It takes 20 seconds for the HomeLink

indicator to start flashing.

Erase the entire HomeLink

memory

When selling your vehicle, be sure to erase the registered codes from the Home-
Link

memory.

Press and hold the 2 outer HomeLink

buttons

for 10 seconds. Check that the HomeLink

indi-

cator light changes from continuously lit in or-
ange to rapidly flashing in green.
All codes registered to memory will be erased.

▶

Vehicles with auto anti-

glare inside rear view mirror

▶

Vehicles with Digital Rear-

view Mirror

2-3. Parking the vehicle

189

Driving the v

ehicle

Refueling

INFORMATION

■

Running out of fuel

When the vehicle has run out of fuel and the hybrid system cannot be started, refuel the
vehicle with at least enough gasoline to make the low fuel level warning light go off.

there is only a small amount of fuel, the hybrid system may not be able to start.

Opening the fuel tank cap

The fuel tank of your vehicle has a special structure, which requires a reduction in
fuel tank pressure before refueling. After the opener switch has been pressed, it
will take several seconds until the vehicle is ready for refueling.

Press the opener to open the fuel filler door.

The fuel filler door will open within about 10 sec-
onds of the switch being pressed. Before refueling
is possible, a message will be shown on the mul-
ti-information display in the instrument cluster to
indicate the progress of the fuel filler door opener.
The fuel filler door will open.

Turn the fuel tank cap slowly and remove it,
then put it into the holder on the fuel filler
door.

WARNING

Always hold the grips on the fuel tank cap and turn it slowly to remove it. A
whooshing sound may be heard when the fuel tank cap is loosened. Wait until the
sound cannot be heard before fully removing the cap. In hot weather, pressurized fuel
may spray out the filler neck and cause injury.

Precautions for refueling

Make sure to select a compatible type of fuel and refuel safely.

*1 :

The specified refueling volume to cause the warning light to turn off when the vehicle

is level is approximately 2.6 gal. [10.0 L, 2.2 Imp.gal.]. This value may vary when the

vehicle is on a slope. Add extra fuel when the vehicle is inclined.

2-4. Refueling

190

WARNING

Observe the following precautions while refueling the vehicle.

●

After exiting the vehicle and before opening the fuel door, touch an unpainted metal
surface to discharge any static electricity.
Also, do not allow anyone that has not discharged static electricity from their body to
come close to the fuel filler door.
Sparks resulting from static electricity discharge may cause fuel vapors to ignite while
refueling.

●

Do not inhale vaporized fuel. Fuel contains substances that are harmful if inhaled.

●

Do not smoke while refueling the vehicle. Doing so may cause the fuel to ignite and
cause a fire.

●

Do not return to the vehicle or touch any person or object that is statically charged.
This may cause static electricity to build up, resulting in a possible ignition hazard.

●

Securely insert the fuel nozzle into the fuel filler neck.

●

Stop filling the tank after the fuel nozzle automatically clicks off.

●

Do not top off the fuel tank.

NOTICE

●

When refueling your vehicle, make sure that the
fuel filler door lock is not pushed by the fuel nozzle
boot, etc., as this may cause a valve to close, possi-
bly resulting in a fuel spill.
If the fuel filler door lock has been pushed, operate
the fuel filler door opener switch in the vehicle
before continuing to refuel.

●

Finish refueling within 30 minutes. If more than 30 minutes passes, the internal valve
closes. In this condition, fuel may overflow during the refueling process. Press the fuel
filler door opener switch again.

●

Do not spill fuel during refueling. Doing so may damage the vehicle, such as causing
the emission control system to operate abnormally or damaging fuel system compo-
nents or the vehicle’s painted surface.

INFORMATION

■

Fuel tank opening for unleaded gasoline

To help prevent refueling with the incorrect fuel, your vehicle has a fuel tank opening
designed to only accommodate the special nozzle on unleaded fuel pumps.

2-4. Refueling

191

Driving the v

ehicle

Close the fuel tank cap

After refueling, turn the fuel tank cap until you
hear a click.

Once the cap is released, it will turn slightly in the
opposite direction.

WARNING

If replacing the fuel tank cap, do not use anything but a genuine Lexus fuel tank cap
designed for your vehicle. Doing so may cause a fire.

INFORMATION

■

When "Check Fuel Cap" is displayed on the multi-information display

The fuel tank cap may be unfastened or loose. Turn the power switch off, check the cap
and tighten it securely. If the message remains, wait a few seconds and then turn the
power switch off once again.

2-4. Refueling

192

Driving when the surrounding area is dark

Using the headlights

The headlights can be operated manually or automatically.

Related Links

Customizable features(P. 739)

Turning the headlights on/off

Do not leave the lights on longer than necessary with the hybrid system off. Doing
so may lead to discharge of the 12-volt battery.

Operating the

switch turns on the lights as follows:

▶

Type A

The side marker, parking, tail, license

plate, instrument panel lights, and daytime
running lights turn on.

The headlights and all the lights listed

above (except daytime running lights) turn
on.

The headlights, daytime running lights

and all the lights listed above turn on and off
automatically.

The daytime running lights turn off.

3-1. Driving when the surrounding area is dark

194

▶

Type B

The side marker, parking, tail, license

plate, instrument panel lights, and daytime
running lights turn on.

The headlights and all the lights listed

above (except daytime running lights) turn
on.

The headlights, daytime running lights

and all the lights listed above turn on and off
automatically.

INFORMATION

■

AUTO mode can be used when

The power switch is in ON.

■

Daytime running light system

●

The daytime running lights illuminate using the same lights as the parking lights and
illuminate brighter than the parking lights.

●

To make your vehicle more visible to other drivers during daytime driving, the daytime
running lights turn on automatically when all of the following conditions are met. (The
daytime running lights are not designed for use at night.)

•

The hybrid system is started

•

The parking brake is released

•

The headlight switch is in the

position

The daytime running lights remain on after they illuminate, even if the parking brake is
set again.

●

For U.S.A.: The daytime running lights can be turned off by turning the headlight

switch to the

position.

●

Compared to turning on the headlights, the daytime running light system offers
greater durability and consumes less electricity, so it can help improve fuel economy.

●

If a turn signal light is in use, the daytime running light, on the same side, is turned off.
For emergency flashers, both are turned off.

*1 :

When the surroundings are bright

3-1. Driving when the surrounding area is dark

195

Driving accor

ding to the conditions

■

Headlight control sensor

The sensor may not function properly if an object is placed on the sensor, or anything
that blocks the sensor is affixed to the windshield. Doing so interferes with the sensor
detecting the level of ambient light and may cause the automatic headlight system to
malfunction.

■

Automatic light off system

●

When the headlights come on:
The lights turn off 30 seconds after a door is opened and closed if the power switch
is turned off. (The lights turn off immediately if

on the key is pressed after all the

doors are locked.)

●

When only the tail lights come on:
The tail lights turn off automatically if the power switch is turned off and the driver’s
door is opened.

To turn the lights on again, turn the power switch to ON, or turn the light switch off once

and then back to

■

Light reminder buzzer

A buzzer sounds when the power switch is turned off or turned to ACC and the driver’s
door is opened while the lights are turned on.

■

12-volt battery-saving function

In order to prevent the 12-volt battery of the vehicle from discharging, if the headlights
and/or tail lights are on when the power switch is turned off the 12-volt battery saving
function will operate and automatically turn off all the lights after approximately 20
minutes. When the power switch is turned to ON, the 12-volt battery-saving function will
be disabled.
When any of the following are performed, the 12-volt battery-saving function is canceled
once and then reactivated. All the lights will turn off automatically 20 minutes after the
12-volt battery-saving function has been reactivated:

●

When the headlight switch is operated

●

When a door or the back door is opened or closed

3-1. Driving when the surrounding area is dark

196

Turning on the high beam headlights

With the headlights on, push the lever for-
ward.

The high beam headlights will turn on.
Pull the lever to its original position to turn the
high beam headlights off.

Pull the lever rearward and release it.

The high beams will flash once.
The high beam headlights can be illuminated
this way even with the headlights off.

Operation of the cornering lights

When any of the following conditions are met, while the headlights (low beam)
are on, the cornering lights will turn on and light up the direction of movement of
the vehicle. The cornering lights are designed to ensure excellent visibility when
turning at intersections or parking at night.

●

The steering wheel is being operated

●

The turn signal lever is being operated

●

The shift position is in R

INFORMATION

■

Cornering light control

●

When vehicle speed is approximately 22 mph (35 km/h) or higher, the cornering
lights will not turn on.

●

The lights will automatically turn off if they remain illuminated for 30 minutes.

Operation of the AFS (Adaptive Front-lighting System)

The AFS (Adaptive Front-lighting System) ensures excellent visibility when turn-
ing at intersections and on curves by automatically adjusting the angle of the
headlights according to vehicle speed and the angle of the tires as controlled by
steering input.
The AFS operates at speeds of 6 mph (11 km/h) or higher.

* :

If equipped

3-1. Driving when the surrounding area is dark

197

Driving accor

ding to the conditions

Automatically changing between the low beam headlights and high
beam headlights

AHS (Adaptive High-beam System)

The Adaptive High-beam System uses a front camera located on the upper
portion of the windshield to detect the brightness of the lights of vehicles ahead,
streetlights, etc., and automatically controls the light distribution of the headlights.

WARNING

■

For safe use

Do not overly rely on the Adaptive High-beam System. Always drive safely, taking care to
observe your surroundings and turning the high beams on or off manually if necessary.

■

To prevent unintentional operation of the Adaptive High-beam System

When it is necessary to disable the system:

→

P.341

System controls

●

According to the vehicle speed, the brightness and illuminated area of the high
beams are adjusted.

●

The high beams are illuminated so that the area around a vehicle ahead is
shaded. (Shaded high beam)
The shaded high beam helps ensure forward visibility while reducing the daz-
zling effect on the drivers of vehicles ahead.

Area illuminated by the high beams

Area illuminated by the low beams

●

According to the distance to a preceding vehicle, the illuminated area of the low
beams is adjusted.

* :

If equipped

3-1. Driving when the surrounding area is dark

199

Driving accor

ding to the conditions

Using the Adaptive High-beam System

Press the Adaptive High-beam System
switch.

Turn the headlight switch to the [AUTO] or

[

] position.

When the headlight switch lever is in the low
beam position, the AHS system will be enabled
and the AHS indicator will illuminate.

INFORMATION

■

System operating conditions

●

When all of the following conditions are met, the high beams will illuminate and the
system will operate:

•

The vehicle speed is approximately 19 mph (30 km/h) or more

•

The area ahead of the vehicle is dark.

●

When all of the following conditions are met, the headlights will change to the shaded
high beams according to the position of vehicles ahead:

•

The vehicle speed is approximately 19 mph (30 km/h) or more

•

The area ahead of the vehicle is dark.

•

There is a vehicle ahead with lights on.

•

There are few streetlights or other lights on the road ahead.

●

If any of the following conditions are met, the system will change to the low beams:

•

The vehicle speed is approximately 16 mph (25 km/h) or lower.

•

The area ahead of the vehicle is not dark.

•

There are many vehicles ahead.

•

There are many streetlights or other lights on the road ahead.

3-1. Driving when the surrounding area is dark

200

■

Front camera detection

●

In the following situations, the high beams may not be automatically changed to the
shaded high beams:

•

When a vehicle cuts in front of your vehicle

•

When another vehicle crosses in front of the vehicle

•

When vehicles ahead are repeatedly detected and then hidden due to repeated
curves, road dividers or roadside trees

•

When a vehicle ahead approaches from a far lane

•

When a vehicle ahead is far away

•

When a vehicle ahead has no lights

•

When the lights of a vehicle ahead are dim

•

When a vehicle ahead is reflecting strong light, such as the headlights of your
vehicle

•

Situations in which the sensors may not operate properly:

→

P.346

●

The high beams may change to the shaded high beams if a vehicle ahead that is using
fog lights without its headlights turned on is detected.

●

House lights, street lights, traffic signals, and illuminated billboards or signs and other
reflective objects may cause the high beams to change to the shaded high beams,
cause the high beams not to change to the shaded high beams, or change the area
that is not illuminated.

●

The following may change the speed at which the shaded areas change or the timing
at which the headlights change to the low beams:

•

The brightness of lights of vehicles ahead

•

The movement and direction of vehicles ahead

•

The distance between the vehicle and a vehicle ahead

•

When a vehicle ahead only has lights illuminated on one side

•

When a vehicle ahead is a two-wheeled vehicle

•

The condition of the road (gradient, curve, condition of the road surface, etc.)

•

The number of passengers and amount of luggage

●

The light distribution control of the headlights may not match the driver's expectations

●

Bicycles and other small vehicles may not be detected.

●

In the following situations, the system may not be able to correctly detect the bright-
ness of the surroundings. This may cause the low beams to remain on or the high
beams to flash or dazzle pedestrians or vehicles ahead. In such a case, it is necessary
to manually change between the high beams and low beams.

•

When there are lights similar to headlights or tail lights in the surrounding area

3-1. Driving when the surrounding area is dark

201

Driving accor

ding to the conditions

Lexus NX350h (2022 year). Manual in english - page 11
