Defender Electric Diagrams. Manual - part 99
HEADER 0290 (K109)
HEADER 0285 (K109)
HEADER 0286 (K109)
HEADER 0288 (K109)
HEADER 0292 (K109)
HEADER 0292 (K109)
A1 (RO) CHASSIS
A15 (WG) CHASSIS
A6 (GP) CHASSIS
A26 (P) CHASSIS + A6 (P) TRAILER
A27 + A2 (RB) CHASSIS
A16 (GW) CHASSIS
A12 (GR) CHASSIS
C1102-1 C0704-1
C1260-4 C0929-4
C0499-5
C0125-3
C0376-1 C0390-1
C0290-2
C1102-1
C0735-3
C0377-3 C0391-3
C0285-2
C0121-2
C0832-1
C0125-2
C1260-5 C0929-5
C0499-6
C0376-6 C0390-6
C0286-9
C1305-1 C1306-1
C0499-2
C1095-2
C1208-1 C0711-1
C0356-3
C0378-1 C0392-1
C0573-4
C1260-6 C0929-6
C0350-1
C0121-3
C0139-1
C0376-2 C0390-2
C0288-5
C1260-2 C0929-2
C0499-7
C1260-3 C0929-3
C0499-4
C0837-2
C0376-5 C0390-5
C0292-15
C1260-1 C0929-1
C0499-1
C0928-2
C0376-4 C0390-4
C0292-1
A1
A15
A6
A6
A26
A2
A27
A16
A12
LAMP-TAIL-RH (A114)
TRAILER PICK-UP (P124)
MOTOR-WIPER-REAR SCREEN (M106)
LAMP-TAIL-LH (A115)
LAMP-TAIL-RH (A114)
TRAILER PICK-UP (P124)
TRAILER PICK-UP (P124)
DIODE (G126)
LAMP-INTERIOR-REAR (B104)
SOCKET-ACCESSORY (V103)
LAMP-TAIL-LH (A115)
LAMP-NUMBER PLATE (A136)
TRAILER PICK-UP (P124)
TRAILER PICK-UP (P124)
TRAILER PICK-UP (P124)
G,1.0,1140
RO,1.5,1105
RO,1.5,3965
RO,1.5,420
RO,1.5,800
WG,0.5,1695
WG,1.0,3935
WG,1.0,840
GP,1.5,4145
GP,1.5,800
GP,1.5,860
GP,1.5,785
P,1.0,2050
P,3.0,3060
P,2.0,230
RB,1.5,850
RB,1.5,800
GW,1.5,765
GW,1.5,4055
GW,1.5,800
GW,1.5,500
GW,1.5,875
GR,1.5,1345
RB,1.5,845
GR,1.5,4025
WG,1.0,1215
RB,1.5,175
GP,1.5,1595
P,3.0,4115
GP,1.5,1005
GR,1.5,800
RO,1.5,965
GR,1.5,500
GR,1.5,905
P,2.0,180
P,3.0,815
P,2.0,1005
RY,1.5,620
GP,1.5,925
RB,1.5,85
RB,1.5,1480
RB,1.5,4085
P,2.0,835
RY,1.5,180
LAMP-DIRECTION
INDICATOR/HAZARD
WARNING-REAR-LH (A119)
LAMP-DIRECTION
INDICATOR/HAZARD
WARNING-REAR-RH (A118)
LAMP-BRAKE-
HIGH MOUNTED (A126)
SENSOR-WATER
FILTER (T194)
FUSE BOX-ENGINE
COMPARTMENT (P108)
SPLICE JOINTS
65.4
DEFENDER
1999 MY
