155

Convenience features

R

Glove box

To open the glove compartment, press
the release button and allow the lid to
drop down. The compartment will be
illuminated when open.

If the compartment is left open the light
will extinguish after approximately 40
minutes.

The glove compartment can be locked
using the key blade and secured for valet
mode.  See USING THE KEY (page 42).

CENTRE CONSOLE

The sliding armrest is hinged at the rear
and has a release button located on the
front of the armrest.

Pull the chromed button upwards to raise
the armrest and gain access to the cubby
box. As the armrest is lifted it slides back
under its own weight allowing full access
to the cubby box.

E91413

E91408

Convenience features

156

L

GARAGE DOOR TRANSCEIVER

The door transceiver is located in the roof
console. It can be programmed to
transmit the radio frequencies of up to
three different transmitters which can be
used to activate garage doors, entry
gates, home lighting, security systems, or
other radio frequency operated devices.

Although this section mainly describes
the procedures for a garage door opener,
it also equally applies to the previously
mentioned applications.

In some countries this feature is also
known as the HomeLink® Universal
Transceiver. The transceiver radio
frequency approval numbers for the USA,
Canada and Mexico are shown below:

USA and Puerto Rico - FCC: K8597
R315.

Canada - CAN: 2145 101 790A.

Mexico -
CFT/D04/AGIT/DGIH/HOM/6068/01 and
7335/01.

For further information, or for assistance,
contact your Jaguar Dealer, or the
supplier by phone or via the internet.For
details, see Information and Assistance.

Before programming

For best results, fit a new battery to the
hand-held transmitter of the garage door
opener (or other device) before
programming. If your garage door opener
receiver (located in the garage) is
equipped with an antenna, ensure that
the antenna is hanging straight down.

E91423

WARNINGS

Do not use the transceiver with
any garage door opener that lacks
the safety stop and reverse

feature as required by safety standards.
Using a garage door opener without
these features increases risk of serious
injury or death.

When programming the
transceiver to a garage door
opener or entry gate, ensure the

area is clear. This will prevent potential
harm or damage as the gate or garage
door will activate during the programme.

CAUTION

This device may suffer from
interference if operated in the
vicinity of a mobile or fixed station

transmitter. This interference is likely to
affect the hand-held transmitter as well
as the in-car transceiver

CAUTION

When programming a device that
may require you to press and
re-press the hand-held transmitter

(cycle), unplug the device during the
cycling process to prevent possible
motor failure.

157

Convenience features

R

To erase all programming

For first time programming, ensure that
the engine is switched off:

1. Ensure that the ignition system is in

convenience mode.

2. Press and hold the two outer buttons

on the transceiver in the overhead
console. Keep the buttons pressed,
the indicator light, A, will illuminate.
The indicator light is part of the
middle button.

3. Release the buttons when the light

begins to flash (this will take
approximately 20 seconds).

All memories in the garage door opener
have now been cleared.

Note: Do not perform this procedure
when programming the additional garage
door opener buttons.

Programming the vehicle

Ensuring that the engine is switched off:

1. Ensure that the ignition system is in

convenience mode.

2. Hold the end of the original garage

door opener hand-held transmitter
approximately 50 to 150 mm (2 to 6
inches) away from the transceiver in
the roof console, keeping the
indicator light, A, in view.

3. Using both hands, simultaneously

press and hold both the desired
garage door opener button on the
overhead console, as shown above,
and the hand-held transmitter
button. Keep both buttons pressed.
The indicator light will flash slowly at
first and then change to a fast flash.
When the indicator light flashes
rapidly, release both buttons. The
rapid flashing light indicates
successful programming.

4. If, after 60 seconds, the indicator light

does not flash rapidly, release both
the transceiver and the hand-held
transmitter buttons and repeat the
procedure starting with Step 2.
Position the hand-held transmitter at
a different angle and or distance.

5. Press and hold the programmed

overhead console garage door
opener button and observe the
indicator light.
• If the indicator is continuous,

programming is complete and your
device should activate when the
garage door opener button is
pressed and held for approximately
1 to 2 seconds and then released.

• If the indicator light blinks rapidly

for two seconds and then turns a
continuous light, proceed with the
following programming instructions
for rolling code device equipment.

Note: To programme additional garage
door opener buttons, begin at Step 2.

1

E91424

Convenience features

158

L

Rolling code device equipment
programming

Note: A second person may make the
following steps quicker and easier as
once the button has been pressed there
are 30 seconds only in which to complete
Step 3.

1. At the garage door opener receiver

(motor head unit) in the garage, locate
the learn or smart button/switch.
• The name of the button or switch

may vary between manufacturers.

2. Press and release the learn or smart

button.

3. Return to the vehicle and firmly press

and hold the programmed garage
door opener button for two seconds
and release.

4. Repeat the press, hold, release

sequence three times to complete the
training process.

The garage door opener in the overhead
console should now activate the rolling
code device.

Reprogramming a single garage
door opener button

To programme a device to previously
trained button:

1. Press and hold the desired

pre-programmed garage door opener
button for at least 20 seconds, but no
longer than 30 seconds, until the
indicator light begins to flash.

2. Without releasing the overhead

console button, position the hand
held transmitter approximately 50 to
150 mm (2 to 6 inches) away from the
transceiver in the overhead console,
keeping the indicator light in view.

3. Carry out Step 3 of Programming the

Vehicle.

Entry gate/Canadian programming

The technology of some entry gates
requires you to press and re-press (cycle)
the hand-held transmitter button every
two seconds during programming.

Continue to press and hold the desired
overhead console button while you cycle
your hand-held transmitter until the
indicator light flashes rapidly.

Information and assistance

If you would like additional information on
the HomeLink® Universal Transceiver,
compatible products or to purchase other
accessories such as the HomeLink®
lighting package, contact your Jaguar
Dealer or HomeLink® at 1-800-355-3515
or on the internet at
www.homelink.jci.com.

Note: Keep the original transmitter for
future use or programming procedures if,
for example, you purchase a new vehicle.

Note: The manufacturer is not
responsible for any radio or TV
interference caused by unauthorised
modifications to this equipment. Such
modifications could void the user’s
authority to operate the equipment.

CAUTION

It is recommended that when you
sell or dispose of the vehicle, the
programmed transceiver buttons

be erased for security purposes.
