6
The armrest will be raised or low鄄
ered manually.
To raise the armrest, pull it up.
To lower it, press the armrest
down.
Adjusting Seatback Angle
To recline the seatback, lean for鄄
ward to you're your weight off it,
then pull up on the recliner control
lever at the outside edge of the
seat. Now lean back until the de鄄
sired seatback angle is achieved.
To lock the seatback into position,
release the recliner control lever.
Adjustable Headrests
The headrests in your JAC may be
raised or lowered by releasing the
lock button on the headrest sup鄄
port. To raise the headrest, pull it
up. To lower it, press the headrest
down. To move the headrest fore鄄
ward, pull on the top. For maxi鄄
mum effectiveness in case of an
accident the headrest should be
adjusted so the top of the headrest
is at the same height as the top of
WARNING:
To minimize risk of personal in鄄
jury in event of a collision or
sudden stop, both the driver
and
passenger
seatbacks
should always be in a nearly
upright position while the vehi鄄
cle is in motion. The protection
provided by the seat belts may
be reduced significantly when
the seatback is reclined. There
is greater risk that the passen鄄
ger will slide under the belt re鄄
sulting in serious injury when
the seatback is reclined.
BEFORE DRIVING YOUR VEHICLE
7
occupant's ears. For this reason,
the use of a cushion that holds the
body away from the seat back
should not be used.
Lumbar Support Adjustment (If in鄄
stalled) (Driver's seat only)
The seats in some JAC are e鄄
quipped with adjustable lumbar
support.
The lumbar support can be adjust鄄
ed in three stages to provide the
most comfortable support.
1. Weak 2. Medium 3.Strong
Seat Cushion Height Adjustment (If
installed )(Driver's seat only)
To raise or lower the front part of
the seat cushion, turn the front
knob forward or rearward. To raise
or lower the rear part of the seat
cushion, turn the rear knob forward
or rearward.
SEAT BELTS (3-Point Type)
To Fasten Your Belt
WARNING:
Do not operate vehicle with the
headrests removed as injury to
an occupant may occur in the
event of an accident. Headrests
may provide protection against
neck injuries when properly ad鄄
justed.
