Engine JAC HFC4DA1-2C. Manual - part 202

星锐专用工具

Tool

Tool

Tool

Tool Number

Number

Number

Number

Tool

Tool

Tool

Tool Name

Name

Name

Name

Illustration

Illustration

Illustration

Illustration

Function/Applied

Function/Applied

Function/Applied

Function/Applied Part

Part

Part

Part

JAC-T8B002

Oil seal puller

For removing oil seal (transmission)

JAC-T8B003

Clutch guider

For center alignment of clutch disc

(transmission)

JAC-T8B004

Input shaft bearing

installer

For installing input shaft bearing (transmission)

JAC-T8B005

Output shaft bearing

installer

For installing output shaft bearing (transmission)

JAC-T8B006

Countershaft front

bearing installer

For installing countershaft front bearing

(transmission)

JAC-T8B007

Input shaft protective

sleeve

For protecting input shaft front end teeth

(transmission)

JAC-T8B008

Output shaft

protective sleeve

For protecting output shaft front end teeth

(transmission)

JAC-T8B009

Transmission bearing

removal tool kit

For removing transmission bearing

(transmission)

JAC-T8B010

Input shaft oil seal

installer

For installing input shaft oil seal (transmission)

JAC-T8B011

Oil seal puller of

transmission rear end

cover

For removing oil seal of rear end cover

(transmission)

JAC-T8B012

Oil seal installer of

rear end cover

For installing oil seal of rear end cover

(transmission)

JAC-T8D001

Steering linkage

drawing die

For disengaging front wheel end control arm ball

joint from steering knuckle (chassis)

JAC-T8D002

Interior trim crow

plate

For prying up interior trim of vehicle
