Removal/Installation

Removal/Installation

Removal/Installation

Removal/Installation

Roof

Roof

Roof

Roof lining

lining

lining

lining

Removal
1.

Remove the negative cable of battery.

2.

Remove curtains.

3.

Remove upper and lower trim panels of B-pillar.

4.

Remove luggage racks on bolt left and right sides.

BP

BP

BP

BP Interior/Exterior

Interior/Exterior

Interior/Exterior

Interior/Exterior Trims

Trims

Trims

Trims

- 71 -

Removal/Installation

Removal/Installation

Removal/Installation

Removal/Installation

Roof

Roof

Roof

Roof lining

lining

lining

lining

5.

Remove interior ceiling lamp 1.

6.

Remove interior ceiling lamp 2.

7.

Remove right sun visor.

8.

Remove left sun visor.

BP

BP

BP

BP Interior/Exterior

Interior/Exterior

Interior/Exterior

Interior/Exterior Trims

Trims

Trims

Trims

- 72 -

Removal/Installation

Removal/Installation

Removal/Installation

Removal/Installation

Roof

Roof

Roof

Roof lining

lining

lining

lining

9.

Remove front interior ceiling lamp.

10. Remove clips of rear roof lining and take down the

rear roof lining.

11. Remove clips of middle roof lining and take down

the middle roof lining.

12. Remove clips of front roof lining and take down

the front roof lining.
