PNEUMATIC SYSTEM - BRAKES

13

Base - February 2003

GRAPHIC SYMBOLS FOR HYDROPNEUMATIC SYSTEMS DIAGRAMS
(CONVERTERS, CYLINDERS AND CALIPERS)

DENOMINATION

SYMBOL

VACUUM SERVOBRAKE

VACUUM SERVOBRAKE

DOUBLE CIRCUIT MASTER CYLINDER

SIMPLE CIRCUIT MASTER CYLINDER

PNEUMO-HYDRAULIC CONVERTER

PNEUMO-HYDRAULIC CONVERTER

HYDRAULIC BRAKE CYLINDER

OPERATOR CYLINDER

BRAKE CYLINDER

SPRING CYLINDER

COMBINED BRAKE CYLINDER

FIXED DISC BRAKE CALIPER

32791

E

URO

C

ARGO

T

ECTOR

12-26 t

14

PNEUMATIC SYSTEM - BRAKES

Base - February 2003

DENOMINATION

SYMBOL

FLOATING DISC BRAKE CALIPER

FLOATING DISC BRAKE CALIPER
WITH PARKING

MECHANICAL

FLOATING

DISC

BRAKE
CALIPER

SERVOCLUTCH

SERVOCLUTCH

32793

32792

E

URO

C

ARGO

T

ECTOR

12-26 t

PNEUMATIC SYSTEM - BRAKES

15

Base - February 2003

DENOMINATION

SYMBOL

“ISO” HALF-COUPLING

A

M

ISO VERSION

“ISO” HALF-COUPLING

A

M

VERSION WITH ISO JOINTS

“CUNA” HALF-COUPLING

A

B

ITALIAN VERSION

“CUNA” HALF-COUPLING

M

A

“NATO” HALF-COUPLING

A

M

NATO VERSION

32793

E

URO

C

ARGO

T

ECTOR

12-26 t

16

PNEUMATIC SYSTEM - BRAKES

Base - February 2003

DENOMINATION

SYMBOL

HALF-COUPLING

1

2

3

5

4

V

A

Z

VERSION WITH MONO-DUCT

HALF-COUPLING

V

A

Z

A

M

VERSION WITH MONO-DUCT

HALF-COUPLING

4

2

12

22

VERSION WITH MONO-DUCT

HALF-COUPLING

4

2

12

22

M

A

1

VERSION WITH MONO-DUCT
