MANUAL TRANSMISSION 7B–39 226RW096 7. Inspect mainshaft. 1. Using a micrometer, measure the outer diameter of the mainshaft journal. Mea- sure Positio n Standard A 37.984 – 38.000 mm (1.4954 – 1.4961 in) B 46.984 – 47.000 mm (1.8498 – 1.8504 in) C 38.979 – 38.995 mm (1.5346 – 1.5352 in) 226RW078 2. Using a micrometer, measure the mainshaft flange thickness. Standard: 5.0 mm (0.197 in) 226RW079 3. Install the mainshaft to V-blocks. 4. Use a dial indicator to measure the mainshaft central portion run-out. Standard: less than 0.015 mm (0.0006 in) 226RW097 |
