7A1–84 TRANSMISSION CONTROL SYSTEM (4L30–E)

Connector List

No.

Connector face

No.

Connector face

B-13

H-41

E-53

(J2)

H-53

E-54

(J1)

H-54

H-8

H-55

H-10

H-56

H-11

H-57

H-24

I-9

H-25

M-6

H-32

M-7

TRANSMISSION CONTROL SYSTEM (4L30–E)

7A1–85

No.

Connector face

No.

Connector face

M-15

M-25

MANUAL TRANSMISSION

7B–1

TROOPER

TRANSMISSION

MANUAL TRANSMISSION

CONTENTS

Service Precaution

7B–1

. . . . . . . . . . . . . . . . . . . . . .

General Description

7B–2

. . . . . . . . . . . . . . . . . . . . .

Diagnosis

7B–3

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Manual Transmission Assembly

7B–4

. . . . . . . . . . .

Removal

7B–4

. . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Installation

7B–8

. . . . . . . . . . . . . . . . . . . . . . . . . . . .

Disassembled View

7B–13

. . . . . . . . . . . . . . . . . . . .

Disassembly

7B–16

. . . . . . . . . . . . . . . . . . . . . . . . . .

Inspection

7B–34

. . . . . . . . . . . . . . . . . . . . . . . . . . . .

Reassembly

7B–36

. . . . . . . . . . . . . . . . . . . . . . . . . .

Main Data and Specifications

7B–62

. . . . . . . . . . . . .

Special Tools

7B–64

. . . . . . . . . . . . . . . . . . . . . . . . . . .

Service Precaution

WARNING: THIS VEHICLE HAS A SUPPLEMENTAL
RESTRAINT SYSTEM (SRS). REFER TO THE SRS
COMPONENT AND WIRING LOCATION VIEW IN
ORDER TO DETERMINE WHETHER YOU ARE
PERFORMING SERVICE ON OR NEAR THE SRS
COMPONENTS OR THE SRS WIRING. WHEN YOU
ARE PERFORMING SERVICE ON OR NEAR THE SRS
COMPONENTS OR THE SRS WIRING, REFER TO
THE SRS SERVICE INFORMATION. FAILURE TO
FOLLOW WARNINGS COULD RESULT IN POSSIBLE
AIR BAG DEPLOYMENT, PERSONAL INJURY, OR
OTHERWISE UNNEEDED SRS SYSTEM REPAIRS.

CAUTION: Always use the correct fastener in the
proper location. When you replace a fastener, use
ONLY the exact part number for that application.
ISUZU will call out those fasteners that require a
replacement after removal. ISUZU will also call out
the fasteners that require thread lockers or thread
sealant. UNLESS OTHERWISE SPECIFIED, do not
use supplemental coatings (Paints, greases, or other
corrosion inhibitors) on threaded fasteners or
fastener joint interfaces. Generally, such coatings
adversely affect the fastener torque and the joint
clamping force, and may damage the fastener. When
you install fasteners, use the correct tightening
sequence and specifications. Following these
instructions can help you avoid damage to parts and
systems.

SECTION

7B–2

MANUAL TRANSMISSION

General Description

A07RW023
