6E–524 TROOPER 6VE1 3.5L ENGINE DRIVEABILITY AND EMISSIONS Manifold Absolute Pressure (MAP) Sensor Removal Procedure 1. Disconnect the negative battery cable. sensor. 055RY00001 3. Remove the bolt securing the MAP sensor to the mounting bracket on the common chamber. 4. Remove the MAP sensor from the mounting bracket. 055RW002 Installation Procedure 1. Install the MAP sensor in the mounting bracket. 055RW002 2. Install the mounting bracket retaining bolt on the common chamber. Tighten D Tighten the bolt to 20 N·m (12 lb ft.). 3. Connect the MAP electrical connector. 055RY00001 4. Connect the negative battery cable. |
