6A–71 ENGINE MECHANICAL (6VE1 3.5L) 015RS012 Legend (1) Number 1 and 4 main bearing upper and lower mm ( in) 1 Size Mark Main Bearing Bore Diameter Crank Shaft Main Journal Diameter 2 Size Mark Crank Shaft Bearing Size Mark (Upper Side) Crank Shaft Bearing Size Mark (Lower Side) Oil Clearance (Reference) 1 68.994-69.000 63.918-63.925 (2.5165-2.5167) 2 Blue Blue 0.030-0.049 (0.0012-0.0019) 1 (2.7163-2.7165) 63.926-63.933 (2.5168-2.5170) 1 Brown Brown 0.028-0.047 (0.0011-0.0019) 2 68.987-68.993 63.918-63.925 (2.5165-2.5167) 2 Brown Brown 0.029-0.048 (0.0011-0.0019) 2 (2.7160-2.7163) 63.926-63.933 (2.5168-2.5170) 1 Green Green 0.027-0.046 (0.0011-0.0018) 3 68.980-68.986 63.918-63.925 (2.5165-2.5167) 2 Green Green 0.028-0.047 (0.0011-0.0019) 3 (2.7157-2.7160) 63.926-63.933 (2.5168-2.5170) 1 Yellow Yellow 0.026-0.045 (0.0010-0.0018) Reassembly 1. Crankshaft (12) D Install the main bearings to the cylinder block and D Be sure that they are positioned correctly. D Apply new engine oil to the upper and lower main NOTE: Do not apply engine oil to the main bearing back 015RS012 |
