Index Isuzu Isuzu Amigo / Axiom / Trooper / Rodeo / VehiCross - service repair manual 1999-2002 year
|
|
REAR SUSPENSION 3D–31 D Install the rubber bushing (Frame side) by using NOTE: When mounting rubber bushings, do not use 901RW061 3. Rubber bushing (Axle side) D Remove the rubber bushing (Axle side) by using 901RW062 D Install the rubber bushing (Axle side) by using 901RW063 Installation 1. Install lateral rod and make sure that the lateral rod is in its correct position. NOTE: When mounting lateral rod, be sure not to use 460RW008 Legend (1) Frame Side 2. Install bolt and nut (Frame side). Tighten the bolt and nut lightly, then retighten them to the specified torque Torque: 137 N·m (101 lb ft) 3. Install nut and washer (Axle side). Tighten the nut lightly, then retighten the nut to the specified torque Torque: 78 N·m (58 lb ft) |
