8A–20 LIGHTING SYSTEM Stoplight Switch (W/O Cruise Control) Removal 1. Disconnect the battery ground cable. and then remove the stoplight switch(2) by turning it. 310RS007 Installation To install, follow the removal steps in the reverse order, 1. Check to see if the brake pedal has been returned by the return spring to the specified position. 2. Turn the stoplight switch(1) clockwise until the tip of the threaded portion of the switch contacts the pedal 3. Turn the switch counterclockwise until the space between the tip of the threaded portion and the pedal 310RS006 |
