6A – 16 ENGINE MECHANICAL

Intake / Exhaust Manifold

N·m (kg·m/lb·ft)

025R200009

For Europe

For Europe

20(2.0/14)

20(2.0/14)

20(2.0/14)

22(2.2/16)

22(2.2/16)

30(3.1/22)

27(2.8/20)

30(3.1/22)

20(2.0/14)

5 4 2 8 9 C

黒

01/0

01/08/30

ENGINE MECHANICAL 6A – 17

Timing Pulley

N·m (kg·m/lb·ft)

020R200002

20(2.0/14)

40(4.1/30)

60

°

-90

°

1st

2nd

10(1.0/87lb•in)

20(2.0/14)

50(5.1/37)

20(2.0/14)

9(0.9/78lb•in)

9(0.9/78lb•in)

6A – 18 ENGINE MECHANICAL

Engine Electricals

N·m (kg·m/lb·ft)

060R200291

A

A

15(1.5/11)

85(8.7/63)

40(4.1/30)

40(4.1/30)

24(2.4/17)

20(2.0/14)

ENGINE MECHANICAL 6A – 19

Injector

N·m (kg·m/lb·ft)

E06R200027

With
spacer type

Without
spacer type

20N·m(2.0kg·m/14 Ib ft)

7N·m(0.7kg·m/61 Ib in)

Recheck tightening torque
after tighten the oil rail

Apply engine oil on the
thread of stud bolts

20N·m(2.0kg·m/14 Ib ft)

Tighten 30N·m(3.1kg·m/22 Ib ft)
Then loosen it again tighten with
25N·m(2.5kg·m/18 Ib ft)

Apply engine oil
both side
