PARKING BRAKES 5D – 9 PARKING BRAKE CABLE 5 7 4 2 3 1 6 7 12 15 13 14 A B 10 8 9 10 11 16 9 8 A B Removal Steps 1. Rear wheels 2. Caliper assembly 3. Rotor (Drum) 4. Holding spring 5. Return spring; upper 6. Return spring; lower 7. Shoe assembly 8. Cable fixing bolt 9. Clip 10. Clip Installation Steps To install, follow the removal steps in the 331RW009 |
