6A-62 ENGINE MECHANICAL 4. Piston Pin If could not be installed piston pin, it is recommend- 100 °C (176 — 212°F). 2) Apply a coat of the engine oil to the piston pin. piston until it makes contact with the snap ring. 4) Check to see if the connecting rod moves smoothly on the piston pin. 5. Snap Ring 1) Use a piston ring replacer to install the three piston rings. Install the piston rings in the order shown in the il- Notice: 2) Apply engine oil to the piston ring surfaces. N6A0272E N6A0273E Legend 1. 1st compression ring Legend A. For 4HE1-TC 1. 1st compression ring N6A0274E N6A0275E |
