Lubrication points
Please use multipurpose greases for lubrication of the following points.
King steering pins (4)

Ends of tie rod (2)

146

OWNER爷S MANUAL

JAC High end Light Trucks

Drag link (2)

Rear leaf spring and spring pin (2)

147

148

Apply Foss EPT-2.5 grease to the following points:
Universal joints and slide bushing

Please apply No.2 or 3 universal automobile lithium-based grease to the fol鄄
lowing parts:
Intermediate bearings

OWNER爷S MANUAL

JAC High end Light Trucks

149

Technical specification

Model

HFC1035KD

HFC1035KD

HFC1042K2RD

HFC1042K3RT

Cabin

Single Cab

Single Cab

Double Cab

Double Cab

Engine

HFC4DA1渊E-玉)

HFC4DA1-1渊E-域)

HFC4DA1-1渊E-域)

HFC4DA1-2B(E-芋)

Type

in line-4,diesel

in line-4,

ind -cooler turbocharged,

diesel

in line-4,

ind-cooler turbocharged,

diesel

in line-4,

ind-cooler turbocharged,

diesel

Displacement (cc)

2771

2771

2771

2771

Compression Ratio

17

17

17

17

Max Power (kw/rpm)

57/3600

68/3600

68/3600

68/3600

Max Torque (N.m/rpm)

174/2100-2300

202/2100-2300

202/2100-2300

202/2100-2300

Transmission

JAC MSB-5M

JAC MSB-5M

JAC MSB-5M

JAC MSB-5M

Speed Ratio

5.529袁2.782袁

1.641袁1袁

0.785袁R尧5.271

5.529袁2.782袁

1.641袁1袁

0.785袁R尧5.271

5.529袁2.782袁

1.641袁1袁

0.785袁R尧5.271

5.529袁2.782袁

1.641袁1袁

0.785袁R尧5.271

Gear Position

1 3 5

2 4 R

1 3 5

2 4 R

1 3 5

2 4 R

1 3 5

2 4 R

Final gear ratio

5.375

5.375

5.375

5.375

Brake system

hydraulic brake

hydraulic brake

hydraulic brake

hydraulic brake

Tyre

7.00R16 Rear single

7.00R16 Rear single

7.00R16 Rear single

7.00R16 Rear single

Overall Size渊mm) 渊L*W*H)

4850*1730*224

4850*1730*2240

4875*1715*2215

4918*1868*2154

Rear body size渊mm冤(L*W*H)

3120*1620*400

3120*1620*400

2080*1620*400

2080*1770*400

Tread (front /rear )渊mm冤

1385/1395

1385/1395

1385/1395

1385/1395

Wheelbase渊mm冤

2490

2490

2490

2490

Min Turing Radius渊m冤

6

6

6

6

Min Ground Clearance渊mm冤

198

198

198

198

Max Speed渊km/h冤

110

110

110

110

Seating Capacity

2

2

2+3

2

Max Gradeability(%)

35

35

35

35

Technical specification

150

OWNER爷S MANUAL

JAC High end Light Trucks

Model

HFC1042K3T

HFC1045KRD

HFC1045KRD

HFC1040K/KR1

Cabin

Single Cab

Double Cab

Double Cab

Single/King Cab

Engine

HFC4DA1-2B(E-芋)

HFC4DA1-2B(E-芋)

HFC4DA1-1渊E-域)

HFC4DA1-1渊E-域)

Type

型式

in line-4,

ind-cooler turbocharged,

diesel

in line-4,

ind-cooler turbocharged,

diesel

in line-4,

ind-cooler turbocharged,

diesel

in line-4,

ind-cooler turbocharged,

diesel

Displacement (cc)

2771

2771

2771

2771

Compression Ratio

17

17.5

17.5

17

Max Power (kw/rpm)

68/3600

68/3600

68/3600

68/3600

Max Torque (N.m/rpm)

202/2100-2300

202/2100-2300

202/2100-2300

202/2100-2300

Transmission

JAC MSB-5M

JAC MSB-5M

JAC MSB-5M

JAC MSB-5M

Speed Ratio

5.529袁2.782袁

1.641袁1袁

0.785袁R尧5.271

5.529袁2.782袁

1.641袁1袁

0.785袁R尧5.271

5.529袁2.782袁

1.641袁1袁

0.785袁R尧5.271

5.529袁2.782袁

1.641袁1袁

0.785袁R尧5.271

Gear Position

1 3 5

2 4 R

1 3 5

2 4 R

1 3 5

2 4 R

1 3 5

2 4 R

Final gear ratio

5.375

B301-4.875

B301-4.875

D803-6.142

Brake system

hydraulic brake

hydraulic brake

hydraulic brake

hydraulic brake

Tyre

7.00R16 Rear single

6.50-16/6.50R16

6.50-16/6.50R16

6.50-16

Overall Size渊mm) 渊L*W*H)

4850*1730*2240

5320*1880*2150

5320*1880*2150

5745*1866*2213

Rear body size渊mm冤(L*W*H)

3120*1620*400

2540*1770*400

2540*1770*400

3930/3600*1770*400

Tread (front /rear )渊mm冤

1385/1395

1580/1395

1580/1395

1420,1440/1395

Wheelbase渊mm冤

2490

2800

2800

3000

Min Turing Radius渊m冤

6

7

7

7

Min Ground Clearance渊mm冤

198

190

190

185

Max Speed渊km/h冤

110

95

95

90

Seating Capacity

2

2+3

2+3

2

Max Gradeability(%)

35

32

32

30

151

Model

HFC1040K/KR1

HFC1045K9T/K9R1T

HFC1045K9T/K9R1T

HFC1045K9/K9R1

Cabin

Single/King Cab

Single/King Cab

Single/King Cab

Single/King Cab

Engine

HFC4DA1渊E-玉)

HFC4DA1-2B(E-芋)

HFC4DA1-2B1(E-芋)

HFC4DA1-1A渊E-域)

Type

in line-4,diesel

in line-4,

ind-cooler turbocharged,

diesel

in line-4,

ind-coolerturbocharged,

diesel

in line-4,

ind-cooler turbocharged,

diesel

Displacement (cc)

2771

2771

2771

2771

Compression Ratio

17

17.5

17.5

17.5

Max Power (kw/rpm)

57/3600

68/3600

80/3600

80/3600

Max Torque (N.m/rpm)

174/2100-2300

202/2100-2300

220/2100-2300

220/2100-2300

Transmission

JAC MSB-5M

JAC MSB-5M

JAC MSB-5M

JAC MSB-5M

Speed Ratio

5.529袁2.782袁

1.641袁1袁

0.785袁R尧5.271

5.529袁2.782袁

1.641袁1袁

0.785袁R尧5.271

5.529袁2.782袁

1.641袁1袁

0.785袁R尧5.271

5.529袁2.782袁

1.641袁1袁

0.785袁R尧5.271

Gear Position

1 3 5

2 4 R

1 3 5

2 4 R

1 3 5

2 4 R

1 3 5

2 4 R

Final gear ratio

D803-6.142

B1DAB0-5.571

B1DAB0-5.571

B1DAB0-5.571

Brake system

hydraulic brake

hydraulic brake

hydraulic brake

hydraulic brake

Tyre

6.50-16

6.50R16/6.50-16

6.50R16/6.50-16

6.50R16/6.50-16

Overall Size渊mm) 渊L*W*H)

5745*1866*2213

5980*1998*2220

5980*1998*2220

5980*1998*2220

Rear body size渊mm冤(L*W*H)

3930/3600*1770*400

4180/3850*1900*400

4180/3850*1900*400

4180/3850*1900*400

Tread (front /rear )渊mm冤

1420,1440/1395

1580/1395

1580/1395

1580/1395

Wheelbase渊mm冤

3000

3308

3308

3308

Min Turing Radius渊m冤

7

14

14

14

Min Ground Clearance渊mm冤

185

185

185

185

Max Speed渊km/h冤

90

95

95

95

Seating Capacity

2

3

3

3

Max Gradeability(%)

30

30

30

30

152

OWNER爷S MANUAL

JAC High end Light Trucks

Model

HFC1045K2/R1

HFC1045K2

HFC1042K

Cabin

Single/King Cab

Single/King Cab

Single Cab

Engine

HFC4DA1-1渊E-域)

HFC4DA1渊E-玉)

HFC4DA1渊E-玉)

Type

in line-4,

ind-cooler turbocharged,

diesel

in line-4,

diesel

in line-4,diesel

Displacement (cc)

2771

2771

2771

Compression Ratio

17.5

17

17

Max Power (kw/rpm)

68/3600

57/3600

57/3600

Max Torque (N.m/rpm)

202/2100-2300

174/2100-2300

174/2100-2300

Transmission

JAC MSB-5M

JAC MSB-5M

JAC MSB-5M

Speed Ratio

5.529袁2.782袁

1.641袁1袁

0.785袁R尧5.271

5.529袁2.782袁

1.641袁1袁

0.785袁R尧5.271

5.529袁2.782袁

1.641袁1袁

0.785袁R尧5.271

Gear Position

1 3 5

2 4 R

1 3 5

2 4 R

1 3 5

2 4 R

Final gear ratio

B1DAB0-5.571

B1DAB0-6.142

D800-6.142

Brake system

hydraulic brake

hydraulic brake

hydraulic brake

Tyre

6.50R16/6.50-16

6.50R16/6.50-16

7.00R16

Overall Size渊mm) 渊L*W*H)

5980*1998*2220

5980*1998*2200

5980*1880*2200

Rear body size渊mm冤(L*W*H)

4180/3850*1900*400

4180/3850*1900*400

4180*1770*380

Tread (front /rear )渊mm冤

1580/1395

1580/1395

1440/1425

Wheelbase渊mm冤

3308

3308

3360

Min Turing Radius渊m冤

14

7

7

Min Ground Clearance渊mm冤

185

185

190

Max Speed渊km/h冤

95

95

100

Seating Capacity

3

3

2

Max Gradeability(%)

30

30

30

153
